TRICONEX DI3361 | DI6503 | 数字量输入模块

1. 核心功能与特性

功能定位：

DI3361 是 TRICONEX 安全控制系统中的 数字量输入模块，用于采集现场设备的开关状态信号（如阀门位置、传感器报警等），适用于高可靠性工业安全系统（如 ESD、F&G）。

核心特性：

冗余设计：支持三重模块冗余（TMR），单点故障不影响系统运行。

隔离保护：通道间电气隔离（≥1500 V DC），抗电磁干扰能力强。

自诊断功能：内置 LED 状态指示灯，实时反馈模块健康状态。

2. 技术规格

参数项： 规格

产品型号：TRICONEX DI3361

输入类型：24 V DC 数字信号（干接点或湿接点）

通道数： 32 通道（可配置为 16 输入 + 16 输出）

响应时间 ：≤10 ms

隔离电压 ：1500 V DC（通道对地）

工作温度 ：-40°C 至 +70°C

防护等级 ：IP67（防尘防水）

通信接口 ：集成至 TRICONEX 背板总线

3. 应用场景

石油与天然气：管道阀门状态监测、海上平台火气报警信号采集。

化工与电力：反应釜安全联锁（SIS）、透平机振动开关信号处理。

核工业：核反应堆紧急停机信号输入、辐射监测设备状态反馈。

Core functions and features

Function Positioning:

DI3361 is a digital input module in the TRICONEX safety control system, used to collect the on-off status signals of on-site equipment (such as valve position, sensor alarm, etc.), and is suitable for high-reliability industrial safety systems (such as ESD, F&G).

Core features:

Redundant design: Supports triple module redundancy (TMR), ensuring that a single point of failure does not affect system operation.

Isolation protection: Electrical isolation between channels (≥1500 V DC), with strong anti-electromagnetic interference ability.

Self-diagnostic function: Built-in LED status indicator light, providing real-time feedback on the health status of the module.

2. Technical Specifications

Parameter item: Specification

Product model: TRICONEX DI3361

Input type: 24 V DC digital signal (dry contact or wet contact)

Number of channels: 32 channels (configurable as 16 inputs + 16 outputs)

Response time: ≤10 ms

Isolation voltage: 1500 V DC (channel to ground)

Operating temperature: -40°C to +70°C

Protection grade: IP67 (Dust and water resistant)

Communication interface: Integrated into the TRICONEX backplane bus

3. Application Scenarios

Petroleum and Natural Gas

Pipeline valve condition monitoring and collection of fire and gas alarm signals on offshore platforms.

Chemical Engineering and Electric Power

Safety interlock (SIS) for reaction vessels and signal processing for turbine vibration switches.

Nuclear industry

Emergency shutdown signal input for nuclear reactors and status feedback of radiation monitoring equipment.
