TRICONEX RO3451 | 9771-210F | 数字量输出模块

技术参数

1. 产品概述

TRICONEX RO3451 是英维思（Invensys）Triconex 安全控制系统中的 开关量输出模块，专为工业自动化环境设计，用于处理数字信号以控制设备的启动、停止或状态切换。其核心特性包括高可靠性、抗干扰能力及模块化设计，适用于安全关键型系统如紧急停车系统（ESD）、火气检测系统（F&G）等 。

2. 核心功能与特性

(1) 抗干扰设计

• 采用 屏蔽电缆、PLC局部屏蔽 及 高压泄放元件，有效抑制电源和信号线干扰 。

• 支持多种接线方式（如双绞线、屏蔽线），适配复杂工业场景 。

(2) 模块化与维护性

• 热插拔设计：支持在线更换故障模块，减少停机时间 。

• 诊断功能：内置 LED 状态指示灯，实时反馈模块健康状态（如通信异常或硬件故障）。

(3) 冗余与扩展性

• 可集成至 Triconex 三重模块冗余（TMR）架构，支持与其他 Triconex 组件（如主处理器、通信模块）无缝扩展 。

• 适用于主机架或扩展机架，最大支持 15 个机架的系统规模

Parameter item specification

Signal type: Digital output (Switch control)

The number of channels is 32 (configurable as 16 inputs + 16 outputs).

Isolation voltage: 500 V DC (between channels)

Operating temperature: -40°C to +70°C

Protection grade IP67 (dustproof and waterproof)

The communication interface is integrated into the Triconex backplane bus

Power supply requirement: 24 V DC (backplane power supply)

1. Product Overview

TRICONEX RO3451 is a switch output module in the Invensys Triconex safety control system. It is specially designed for industrial automation environments and is used to process digital signals to control the start, stop or state switching of equipment. Its core features include high reliability, anti-interference ability and modular design, and it is suitable for safety-critical systems such as emergency shutdown systems (ESD), fire detection systems (F&G), etc.

2. Core Functions and Features

Anti-interference design

Shielded cables, partial shielding of PLC and high-voltage discharge components are adopted to effectively suppress the interference of power and signal lines.

Supports multiple wiring methods (such as twisted-pair wires and shielded wires), and is suitable for complex industrial scenarios.

(2) Modularity and maintainability

Hot-swappable design: Supports online replacement of faulty modules to reduce downtime.

Diagnostic function: Built-in LED status indicator light, providing real-time feedback on the health status of the module (such as communication abnormalities or hardware failures).

(3) Redundancy and scalability

It can be integrated into the Triconex Triple Module Redundancy (TMR) architecture and supports seamless expansion with other Triconex components, such as the main processor and communication modules.

Suitable for host racks or expansion racks, it supports a system scale of up to 15 racks at most
