DL-1200RTU Siemens 伺服电机模块 控制电机的旋转

DL-1200RTU伺服电机模块是伺服系统的一部分，它接收来自伺服放大器的控制信号，控制电机的旋转。伺服电机模块包括伺服电机和伺服驱动器，它们通常组合使用。

伺服电机模块的特点：

精度高。

调速范围宽。

动态性能好。

体积小，功率大。

DL-1200RTU伺服驱动器的工作原理是在控制信号的作用下驱动执行电机，其内部结构由电源电路、继电器板电路、主控板电路、驱动板电路及功率变换电路组成。

伺服驱动器在伺服控制系统中相当于大脑，执行电机相当于手脚，主要就是调节电机的转速，是一个自动调速系统。

伺服驱动器具体工作原理为，在继电器板的作用下，发送控制信号和检测信号，完成双闭环控制，包括转速调节和电流调节，实现执行电机的转速控制和换相控制。DL-1200RTU驱动器的驱动板从主控板接受信号驱动功率变换电路，实现执行电机的正常工作。

伺服与驱动单元的组成主要包括伺服控制单元、功率驱动单元、通讯接口单元、伺服电动机及相应的反馈检测器件。

DL-1200RTU伺服控制单元包括位置控制器、速度控制器、转矩和电流控制器等。功率驱动单元通过三相全桥整流电路对输入的三相电或者市电进行整流，得到相应的直流电，再通过逆变器变频输出交流电来驱动伺服电机。通讯接口单元负责传输指令和反馈信号。

DL-1200RTU Siemens 伺服电机模块 控制电机的旋转

The DL-1200RTU servo motor module is part of the servo system, which receives the control signal from the servo amplifier and controls the rotation of the motor. The servo motor module consists of a servo motor and a servo driver, which are usually used in combination.

Servo motor module features:

High precision.

Wide speed range.

Good dynamic performance.

Small size, large power.

The working principle of the DL-1200RTU servo driver is to drive the executive motor under the action of the control signal, and its internal structure is composed of the power supply circuit, the relay board circuit, the main control board circuit, the driver board circuit and the power conversion circuit.

The servo drive is equivalent to the brain in the servo control system, and the execution motor is equivalent to the hands and feet, which is mainly to adjust the speed of the motor and is an automatic speed regulation system.

The specific working principle of the servo driver is that under the action of the relay board, the control signal and the detection signal are sent to complete the double closed-loop control, including speed adjustment and current adjustment, to realize the speed control and commutation control of the motor. The drive board of the DL-1200RTU driver receives the signal from the main control board to drive the power conversion circuit and implement the normal operation of the motor.

The components of servo and drive unit mainly include servo control unit, power drive unit, communication interface unit, servo motor and the corresponding feedback detection device.

The DL-1200RTU servo control unit includes position controller, speed controller, torque controller and current controller. The power drive unit rectified the input three-phase or mains through the three-phase full bridge rectifier circuit to obtain the corresponding direct current, and then output alternating current through the inverter frequency conversion to drive the servo motor. The communication interface unit is responsible for transmitting instructions and feedback signals.
