VSM-CCA  多功能卡件 提供混合模式

VSM-CCA-XP有一组下降的特性。例如dot1Q是唯一支持封装。LACP不能使用端口上配置滞后。港口服务可以直接使用SAP的一个循环。如果弹性需要，或需要更多的能力，可以配置滞后。可以配置为VSM-CCA-XP

VSM-CCA MDA或VSM-CCA-XP MDA。当配置为VSM-CCA-XP CCA时这不是一个成员组。

VSM-CCA-XP MDA提供混合模式以简化配置，并在插入IOM卡时提供高容量VSM.完整的转发路径带宽(在本例中为25 Gb/s)可用，允许在单个MDA上进行高达25Gb/s的单个会话。

VSM-CCA-XP有两个端口，端口x/x/1和端口x/x/2，它们在内部连接。配置与使用具有dot1Q封装的以太网混合端口的物理环回端口非常相似。使用以太网VLAN标记连接SAP。

以下限制适用于VSM-CCA-XP的配置:

虽然LAG可用，但不允许使用LACP。

以太网 CFM仅在VSM上配置了Eth-Ring (以太网环使用以太网MEPS进行控制)时可用。

不支持宽带网络网关的ATM/L以太网最后—英里感知QoS.

以下是预配为VSM-CCA-XP MDA的MDA的示例配置。

本节简要概述了在MDA、路由器、路由器接口和服务上配置VSM时应执行的任务。

在系统中将一个或多个CCA预配为MDA。

在系统上创建VSM CCAG。

·配置CCAG路径带宽、路径权重和总体带宽参数。·将成员CCA预配到CCAG中。

·使用CCAG、路径和CCID 预配服务SAP以进行交叉连接。

将路由的网络IP接口绑定到CCAG、路径和CCID，以便进行交叉连接。

配置VSM CCAG组件

使用下面显示的CLI语法配置以下实体:

在MDA上调配VSM

交叉连接网络IP接口·预配CCAG参数配置路径组件交叉连接服务

在MDA上调配VSM

在系统中使用CCA模块之前，必须将CCA调配到MDA插槽中。必须修改MDA置备命令以支持置备CCA适配器类型。每个CCAG最多可以配置8个成员CC4。

VSM-CCA  多功能卡件 提供混合模式

Vsms-cca is the Ethernet VSMS-CCA-XP brand.

Vsms-cca-xp has a set of declining features. For example, dot1Q is the only one that supports encapsulation. LACP cannot be configured with a lag on the port. Port services can use a loop directly from SAP. If elasticity is required, or more capability is required, hysteresis can be configured. It can be set to VSM-CCA-XP

VSM-CCA MDA or VSM-CCA-XP MDA. This is not a member group when configured as VSM-CCA-XP CCA.

The VSMS-CCA-XP MDA provides a hybrid mode to simplify configuration and provides a high-capacity VSM when inserting an IOM card. The full forwarding path bandwidth (25Gb/s in this case) is available, allowing for a single session of up to 25Gb/s on a single MDA.

Vsms-cca-xp has two ports, port x/x/1 and port x/x/2, which are connected internally. The configuration is very similar to a physical loopback port using an Ethernet hybrid port with dot1Q encapsulation. Connect to SAP using Ethernet VLAN tags.

The following restrictions apply to the configuration of VSM-CCA-XP:

While LAG is available, LACP is not allowed.

Ethernet CFM is available only when the VSM is configured with the Eth Ring (the Ethernet ring is controlled by Ethernet MEPS).

ATM/L Ethernet last-mile aware QoS is not supported for broadband network gateways.

The following is an example configuration of the MDA configured as the VSM-CCA-XP MDA.

This section provides a brief overview of the tasks to be performed when configuring the VSM on the MDA, routers, router interfaces, and services.

Configure one or more CCAs as MDAs in the system.

Create the VSM CCAG on the system.

· Configure CCAG path bandwidth, path weight, and overall bandwidth parameters. · Allocate member CCAs to CCAG.

· Use CCAG, Path and CCID pre-configured service SAP for cross-connection.

Bind the network IP interface of the route to the CCAG, path, and CCID for cross-connection.

Configure the VSM CCAG component

Configure the following entities using the CLI syntax shown below:

Configure the VSM on the MDA

Cross-connect network IP interface · Pre-configured CCAG parameters Configure the path component cross-connect service

Configure the VSM on the MDA

Before using the CCA module in the system, the CCA must be deployed to the MDA slot. The MDA provisioning command must be modified to support the provisioning of the CCA adapter type. Each CCAG can be configured with a maximum of 8 member CC4s.
