F404002A  VISTA 总线接模块

VISTA总线接口模块Steinstein

部件号:F404002A

产品名称:VISTA总线接模块

产品情况:停产

产品包装:原包装

VISTA F404002A总线接模块，是用于总线扩充的模块，可以扩展成2个回路。

VISTA F404002A总线接模块接线方式为：端口接J8左起第一针，6端口接J8左起第七针，7、8端口接主板7、6端口供电。

总线系统一般由传输线+接口+总线控制器组成，其电气特性为：每根传输线上信号的传递方向和有效电平范围，分为单向总线（单工），双向总线（全双工、半双工）。最基本的电气特性为：在任一时刻，只能有一个方向的信息流动，不允许有相向行为。可以一发一收，一发多收；不能多发一收，多发多收。F404002A挂接在总线上的主设备，在任意时刻只允许有一个主设备向总线上发送数据。

总线系统按照传递信息的不同被分为三类：

数据总线：用于传输数据，是双向线。

地址总线：用于传输明确的地址信息，是单向线。

控制总线：用于传输CPU发出的控制信号，是双向线。
