CE620-1 ATEN 信号延长器

型号：CE620-1

品牌：ATEN

ATEN宏正CE620 USB DVI HDBaseT"2.0 KVM信号延长器整合HDBaseTT2.0技术，可提供市面上可靠的视频、音频、USB和RS-232信号传输方式。CE620通过单一Cat5e/6线缆传输高质量DVI视频、PCM双声道数字音频、USB 2.0和RS-232信号，距离可达100米。CE620的线缆安装简易并支持各种信号，适合需要便利远程访问的应用，例如交通控制中心、医疗院所、工业仓库和延伸工作站等地。

特性

HDBaseTTM2.0技术

·通过单一以太网络线缆延长视频、音频、USB及RS-232信号·EDID缓冲器可确保顺利开机并以最高质量显示

·增强位错误侦测与修正，可在高画质视频传输期间防止信号干扰远距离高视频质量

HDBaseT标准模式-分辨率高达1920 x 1200@100米-HDBaseT”远距模式-分辨率高达1920 x 1080@150米远距模式切换开关-快速切换HDBaseTT"标准及远距模式整合式USB 2.0连接端口-确保周边设备的高传输速度支持双声道PCM数字音频-确保高质量音频传输

支持通过按钮或快速键执行PC唤醒功能

内建8KV/15KV静电保护(接触放电8KV;空气放电15KV)附注:CE620不支持HDCP.

规格

Function:CE620L

接口:KVM端口

1 x DVI-D 母头(白)

1 x USB TypeB母头(白)1 x Mini立体声插孔母头(绿)1 x Mini立体声插孔母头(粉红)

控制端连接端口:N/A

包装明细

1x CE620L USB DVI HDBaseT 2.0 KVM信号延长器(本地设备)1x CE620R USB DVI HDBaseT 2.0 KVM信号延长器(远程设备)1x定制 DVI KVM线缆组

2x电源适配器

2x机架安装配件8x脚垫

CE620-1 ATEN 信号延长器

Model: CE620-1

Brand: ATEN

ATEN CE620 USB DVI HDBaseT"2.0 KVM Signal extender integrates HDBASET 2.0 technology to provide reliable video, audio, USB and RS-232 signal transmission methods on the market. The CE620 transmits high-quality DVI video, PCM dual-channel digital audio, USB 2.0 and RS-232 signals over a single Cat5e/6 cable over distances of up to 100 meters. Easy cable installation and support for a variety of signals make the CE620 ideal for applications that require easy remote access, such as traffic control centers, medical facilities, industrial warehouses, and extended workstations.

peculiarity

Hdbase TM2.0 technology

· Extended video, audio, USB and RS-232 signals via a single Ethernet cable ·EDID buffer ensures smooth boot and the highest quality display

· Enhanced bit error detection and correction to prevent signal interference with long distance high video quality during high definition video transmission

HDBaseT Standard Mode - Resolution up to 1920 x 1200@100 m -HDBaseT "Remote Mode - Resolution up to 1920 x 1080@150 m Remote Mode Toggle Switch - Quickly switch HDBaseTT" standard and remote mode integrated USB 2.0 Connection port - Ensures high transmission speeds of peripheral devices support dual channel PCM digital audio - ensures high quality audio transmission

Supports the PC wake-up function by pressing buttons or quick keys

Built-in 8KV/15KV electrostatic protection (contact discharge 8KV; Air discharge 15KV) Note: The CE620 does not support HDCP.

specification

Function:CE620L

Port :KVM port

1 x DVI-D Female head (white)

1 x USB TypeB Female head (white)1 x Mini stereo Jack female head (Green)1 x Mini stereo Jack female head (Pink)

Connection port of the controller :N/A

Packing detail

1x CE620L USB DVI HDBaseT 2.0 KVM Signal Extender (local device)1x CE620R USB DVI HDBaseT 2.0 KVM Signal Extender (remote device)1x Custom DVI KVM cable group

2x power adapter

2x rack mounting accessories 8x foot pads
