CE311 CAPLUGS 电子元器件

编号:376-CE-311

制造商编号:CE-311

制造商:Caplugs

主要信息

产品系列：Telemecanique Safety switches xcs

产品类型：安全开关

组件名称：XCSE

设计：长方形

材料：金属

操纵头类型：键控转塔头

触点类型：2NC+1NO

触点动作：慢中断，先断后合

电磁触点类型和组成：1NC+1NO(慢中断，同时)

电缆进线孔：2带孔进线适用Pg 13.5

电磁铁锁定：螺线管去能时锁定，通电时解锁

额定电源电压[us]：24 v- 20...10 %

电缆外径：9...12 mm

电气连接：端子,夹紧力:1x 0.5...2x 1.5 mm2带有或不带电缆末端

极数：3

有关锁的描述：带有联锁，使用电磁阀锁定

本地信号指示：2LED(绿色或橙色) for防护装置开启/防护装置关闭锁定:

信号电路电压：24/48v(电压限制:20...52 V)

补充信息

强制打开：带NC触头

电源电压类型：Ac/Dc

供电频率：50/60 Hz

负载系数：1

功耗VA:10 VA浪涌10 VA已密封

信号电路类型：Ac/Dc

信号电路功能：7 mA

机械寿命:1000000次

最小制动速度:0.01 m/s

最大操动速度:0.5 m/s

额定工作电流[le]:0.55A在..上126 v, DC-13,Q300符合 EN/IEC 60947-5-10.27A在...上250 v, DC-13,Q300符合EN/IEC 60947-5-13A在..上120 v,AC-15,B300符合EN/IEC 60947-5-11.5A在...上240 v，AC-15,B300符合EN/IEC 60947-5-1

约定封闭发热电流[Ithe]:6A

额定绝缘电压[ui]:50v符合EN/IEC 60947-1适用信号回路

额定冲击耐受电压[uimp]:6 kV符合EN/IEC 60947-5-1

保护类型:过压保护适用信号回路

短路保护:10A熔丝管类型gG (gl)

插片强制抽出rtc:2000 N

Minimum actuator force for extraction:20 N

最大操作频率:10次/分钟用于最高耐用性

安全等级:可以达到4类带相应监控系统与正确接线符合EN/ISO 13849-1可以达到PL=e带相应监控系统与正确接线符合EN/ISO 13849-1可以达到SIL3带相应监控系统与正确接线符合EN/IEC 61508

安全可靠的数据:B10d = 5000000价值由20年生命时间确定，受机械或接触磨损限制

本体材料:zamak

头部材料:zamak

深度:44 mm

高度:146 mm

宽度:98 mm

净重:1.14 kg

环境

符合标准:EN/IEc 60204-1EN/IEC 60947-5-1EN 1088/ISO 14119EN/ISO 12100UL 508

cSA C22.2 No 14

产品认证:uLCSA

保护处理:TC

运行温度:-25...40 °c

贮存环境温度:-40...70 C

抗振动:5 gn (f= 10..500 Hz)符合IEC 60068-2-6

抗冲击:10 gn适用11 ms符合IEC 60068-2-27

电击保护级别:级别I符合EN/IEC 61140

IP保护等级:IP67符合EN/IEC 60529 and EN/IEC 60947-5-1

CE311 CAPLUGS 电子元器件

Number :376-CE-311

Manufacturer Number :CE-311

Manufacturer :Caplugs

Main information

Product line: Telemecanique Safety switches xcs

Product type: Safety switch

Component name: XCSE

Design: Rectangular

Material: Metal

Control head type: keyed turret head

Contact type: 2NC+1NO

Contact action: slow break, break first and then close

Electromagnetic contact type and composition: 1NC+1NO(slow interrupt, simultaneously)

Cable entry hole: 2 For PG-13.5 with holes

Electromagnet lock: lock when the solenoid is deenergized, unlock when energized

Rated supply voltage [us] : 24 v-20... 10%

Cable outer diameter: 9... 12 mm

Electrical connection: terminal, clamping force :1x 0.5... 2x 1.5 mm2 with or without cable end

Number of poles: 3

Description of lock: With interlock, use solenoid valve lock

Local signal indicator: 2LED(green or orange) for guard on/Guard off Lock:

Signal circuit voltage: 24/48v(voltage limit :20... 52 V)

Supplementary information

Forced open: with NC contact

Supply voltage type: Ac/Dc

Power supply frequency: 50/60 Hz

Load factor: 1

Power consumption VA:10 VA Surge 10 VA sealed

Signal circuit type: Ac/Dc

Signal circuit function: 7 mA

Mechanical life :1000000 times

Minimum braking speed: 0.01m /s

Maximum operating speed: 0.5m /s

Rated operating current [le]:0.55A in... The upper 126 v, DC-13,Q300 comply with EN/IEC 60947-5-10.27A in... Upper 250 v, DC-13,Q300 compliant with EN/IEC 60947-5-13A in... Upper 120 v,AC-15,B300 compliant with EN/IEC 60947-5-11.5A in... Upper 240 v, AC-15,B300 compliant with EN/IEC 60947-5-1

Conventional closed heating current [Ithe]:6A

Rated insulation voltage [ui]:50v in accordance with EN/IEC 60947-1 applicable signal circuit

Rated impulse withstand voltage [uimp]:6 kV in accordance with EN/IEC 60947-5-1

Protection type: Overvoltage protection for signal circuits

Short circuit protection :10A fuse tube type gG (gl)

Insert forced extraction rtc:2000 N

Minimum actuator force for extraction:20 N

Maximum operating frequency :10 times/min for maximum durability

Safety level: can achieve 4 types with the corresponding monitoring system and correct wiring in accordance with EN/ISO 13849-1 can achieve PL=e with the corresponding monitoring system and correct wiring in accordance with EN/ISO 13849-1 can achieve SIL3 with the corresponding monitoring system and correct wiring in accordance with EN/IEC 61508

Safe and reliable data :B10d = 5000000 value is determined by a 20-year life time, limited by mechanical or contact wear

Body material :zamak

Head material :zamak

Depth :44 mm

Height :146 mm

Width :98 mm

Net weight: 1.14kg

environment

Standard :EN/IEc 60204-1EN/IEC 60947-5-1EN 1088/ISO 14119EN/ISO 12100UL 508

cSA C22.2 No 14

Product Certification :uLCSA

Protection process :TC

Operating temperature :-25... 40 °c

Storage ambient temperature :-40... 70 C

Vibration resistance :5 gn (f= 10... 500 Hz) in accordance with IEC 60068-2-6

Shock resistance :10 gn for 11 ms according to IEC 60068-2-27

Shock protection Level: Level I complies with EN/IEC 61140

IP protection level :IP67 in accordance with EN/IEC 60529 and EN/IEC 60947-5-1
