XVME-542  模拟输入/输出模块  支持透明和同步通道更新模式

产品型号：XVME-542

XVME-542 模拟输入/输出模块是一个强大的VME总线兼容的I/0模块，可以执行16位A/D和12位D/A转换XVME-542包含64个单端、32个差分或64个伪差分模拟输入通道。输入通道可编程为五种操作模式之一:随机通道、顺序通道、单通道、外部触发或自动扫描。自动扫描可在8、16、32或64个通道上进行。单个通道增益可在三个跳线选择范围之内通过软件编程实现。

该XVME-542还包含8个模拟输出通道，这些输出通道可以配置为电压或电流输出。支持透明和同步通道更新模式。

该XVME-542是引脚兼容的XVME-540模拟输入/输出模块同时提供更高的分辨率，速度和通道数。

特点

64个单端或32个兰分16位输入通道8个12位模拟输出通道

单通道模式下100 KHz的吞吐量单通道模式下的FSR精度为0.003%6

易于使用的自动扫描模式

软件可编程的单独输入增益

可编程中断定时器

同时输出模式

应用程序

数据采集

过程控制

压力和温度传感机器控制

Product model: XVME-542

The XVME-542 analog input/Output module is A powerful VME bus-compatible I/0 module that can perform 16-bit A/D and 12-bit D/A conversions XVME-542 contains 64 single-ended, 32 differential, or 64 pseudo-differential analog input channels. The input channel can be programmed into one of five modes of operation: random channel, sequential channel, single channel, externally triggered or automatically scanned. Automatic scanning can be performed on 8, 16, 32 or 64 channels. A single channel gain can be achieved by software programming within three jumper selection ranges.

The XVME-542 also contains eight analog output channels that can be configured as voltage or current outputs. Supports transparent and synchronous channel update modes.

The XVME-542 is a pin-compatible XVME-540 analog input/output module that simultaneously offers higher resolution, speed, and channel count.

peculiarity

64 single-ended or 32 LAN fen 16-bit input channels 8 12-bit analog output channels

Throughput of 100 KHz in single channel mode FSR accuracy in single channel mode is 0.003%6

Easy to use automatic scanning mode

Software programmable individual input gain

Programmable interrupt timer

Simultaneous output mode

Application program

Data acquisition

Process control

Pressure and temperature sensing machine control
