ICSTRIPLEX T9432  输入输出模块控制层；控制站是整套系统的基础，控制站内部有控制器、I/O模块、现场总线模块及现场总线仪表。控制器负责现场数据的处理，控制器向下与I/O模块连接，向上与控制网络连接。I/O模块主要跟现场仪表连接，负责过程变量输入信号的采集和向现场执行器或者输出模拟量信号（1-5v或4-20mA）。I/O模块它又分模拟量卡件和数字量卡及脉冲量卡件等。比如热工四大参数温度、压力、流量、液位都属于连续性变量。

ICSTRIPLEX T9432  是整个控制系统的中心，有操作员站、工程师站、计算机网关。操作员站它就是给当值人员提供对生产过程监视、控制、管理。工程师站提供工程师对系统的维护、系统的组态。计算机网关是控制网络和生产管理网络的桥梁。最高级别生产管理级，它的主要设备就是PC机，有很多计算机组成负责管理整个生产流程！因此它的设计和配置是根据企业生产要求来的。

ICSTRIPLEX T9432  输入输出模块

ICSTRIPLEX T9432 Controller Control layer; The control station is the foundation of the whole system. The control station has controller, I/O module, fieldbus module and fieldbus instrument. The controller is responsible for the processing of field data. The controller is connected to the I/O module downward and the control network upward. The I/O module is mainly connected to the field instrument and is responsible for the acquisition of the input signal of the process variable and the output of the analog signal (1-5v or 4-20mA) to the field actuator. I/O module it is divided into analog card and digital card and pulse card. For example, the four major thermal parameters temperature, pressure, flow, liquid level are continuous variables.

The ICSTRIPLEX T9432 is the center of the entire control system, with operator stations, engineer stations, and computer gateways. Operator station It is to provide on-duty personnel to monitor, control and manage the production process. The engineer station provides engineers for system maintenance and system configuration. The computer gateway is the bridge between the control network and the production management network. The highest level of production management, its main equipment is the PC, there are many computers responsible for managing the entire production process! Therefore, its design and configuration are based on the production requirements of the enterprise.
