ICSTRIPLEX  T8480C  工控模块专为单一和冗余配置而设计。该模块有 8 个电流输入通道。输入电阻为 250 欧姆。 该模块将外部发射器电源分配给每个通道。这增加了一个简单的连接，将电源分配到2线或3线变送器。变送器功率受到监控和电流限制。所有八个通道都与模块总线隔离在一个组中。模块的电源由模块总线上的 24 V 产生。符合 NAMUR 推荐的 NE43，并支持可配置的超量程和下量程限制。

ICSTRIPLEX  T8480C  工控模块的计算机，它与控制站不同，有着丰富的外围设备和人机界面。在人机界面方面，逐渐过渡为以GUI图形用户界面为平台并采用鼠标，组态时制作流程图和控制回路图等采用菜单、窗口等，使人机界面友好。第三代DCS操作站是在个人计算机（PC）及Windows操作系统普及和通用监控图形软件已商品化的基础上诞生的。

DDE或OPC接口技术，以太网接口与管理网络相连。DCS系统组态、操作站组态、控制站组态均有相应软件，为DCS用户的工程设计人员提供人机界面。有的DCS的采用通用监控图形软件，或以此类软件为核心，进行二次开发。

因为数据通信标准牵涉到网络结构、通信介质（信道）、通信协议、IEEE802.4令牌总线传输方式和IEEE802.5令牌环网传输方式的通信协议在DCS系统中应用最广，是否能够成为今后DCS的通讯标准，还有待观察。

ICSTRIPLEX  T8480C  工控模块

The ICSTRIPLEX T8480C industrial control module is designed for single and redundant configurations. The module has 8 current input channels. The input resistance is 250 ohms. This module allocates external transmitter power to each channel. This adds a simple connection that distributes power to a 2 - or 3-wire transmitter. Transmitter power is monitored and current limited. All eight channels are isolated from the module bus in a group. The power supply of the module is generated by 24 V on the module bus. Complies with NAMUR's recommended NE43 and supports configurable overrange and down-range limits.

ICSTRIPLEX T8480C industrial control module of the computer, it is different from the control station, has a wealth of peripheral equipment and human-machine interface. In the man-machine interface, gradually transition to the GUI graphical user interface as the platform and the use of mouse, the configuration of the production of flow charts and control loop diagrams using menus, Windows, etc., to make the man-machine interface friendly. The third generation DCS operating station was born on the basis of the popularity of personal computers (PCS) and Windows operating systems and the commercialization of general monitoring graphics software.

DDE or OPC interface technology, Ethernet interface connected to the management network. DCS system configuration, operation station configuration, control station configuration have corresponding software, for DCS users to provide a man-machine interface. Some DCS use general monitoring graphics software, or such software as the core, secondary development.

Because the data communication standard involves the network structure, communication medium (channel), communication protocol, IEEE802.4 token bus transmission mode and IEEE802.5 token ring network transmission mode communication protocol in the DCS system is the most widely used, whether it can become the DCS communication standard in the future, it remains to be seen.
