ICS T8110B Trusted TMR处理器是一种基于三模块冗余的容错设计（TMR）体系结构，以锁定步进配置操作。图1以简化方式显示术语，可信TMR处理器模块的基本结构。

ICS T8110B模块包含三个处理器故障控制区域（FCR），每个区域包含一个摩托罗拉Power PC系列处理器及其相关存储器（EPROM、DRAM、闪存ROM、，和NVRAM）、存储器映射I/O、表决器和粘合逻辑电路。每个处理器FCR都有对另外两个处理器的FCR内存进行三分之二（2oo3）的读取访问消除发散操作的系统。

T8110B  ICS TRIPLEX  工业自动化

The ICS T8110B Trusted TMR processor is a fault-tolerant design (TMR) architecture based on three-module redundancy to lock in step-configuration operations. Figure 1 shows the basic structure of the term, trusted TMR processor module, in a simplified manner.

The ICS T8110B module contains three processor fault control areas (FCRS), each containing a MOTOROLA Power PC series processor and its associated memory (EPROM, DRAM, flash ROM, and NVRAM), memory mapped I/O, votor, and adhesive logic circuits. Each processor FCR has a system that performs a two-thirds (2oo3) read access de-divergence operation on the FCR memory of the other two processors.
