安全回路是保护负载或控制对象以及防止操作错误或控制失败而进行连锁控制的回路。在直接控制负载的同时，安全保护回路还给PLC输入信号，以便于PLC进行保护处理。安全回路一般考虑以下几个方面。

（1）短路保护应该在PLC外部输出回路中装上熔断器，进行短路保护。最好在每个负载的回路中都装上熔断器。

（2）互锁与联锁措施除在程序中保证电路的互锁关系，PLC外部接线中还应该采取硬件的互锁措施，以确保系统安全可靠地运行。

（3）失压保护与紧急停车措施PLC外部负载的供电线路应具有失压保护措施，当临时停电再恢复供电时，不按下“启动”按钮PLC的外部负载就不能自行启动。这种接线方法的另一个作用是，当特殊情况下需要紧急停机时，按下“急停”按钮就可以切断负载电源，同时“急停”信号输入PLC。

（4）极限保护在有些如提升机类超过限位就有可能产生危险的情况下，设置极限保护，当极限保护动作时直接切断负载电源，同时将信号输入PLC。

用户可以根据具体需求选择适合的继电器类型，并进行灵活的配置和连接。高电压和高电流测量：该模块支持高电压和高电流的测量应用。它提供了高电压和高电流输入通道，可安全地测量和控制高电压和高电流信号，适用于电力、电子设备测试和控制等应用领域。强大的软件支持模块配备了 NI-DAQmx 驱动软件，提供了丰富的功能和易于使用的编程接口。用户可以使用 LabVIEW、C/C++、Python 等常用编程语言进行编程和控制，方便快速地实现继电器开关操作。

ICS TRIPLEX T8403C PLC模块卡件

Safety loop is a loop for chain control to protect load or controlled object and prevent operation error or control failure. While directly controlling the load, the safety protection circuit also inputs signals to the PLC, which is convenient for the PLC to carry out protection processing. The safety loop generally considers the following aspects.

(1) short circuit protection should be installed in the PLC external output circuit fuse, short circuit protection. It is best to install a fuse in the loop of each load.

(2) Interlocking and interlocking measures In addition to ensuring the interlocking relationship of the circuit in the program, hardware interlocking measures should also be taken in the external wiring of PLC to ensure the safe and reliable operation of the system.

(3) Pressure loss protection and emergency stop measures The power supply line of PLC external load should have pressure loss protection measures. When power supply is resumed after temporary power failure, the external load of PLC cannot start by itself without pressing the "Start" button. Another function of this wiring method is that when an emergency stop is needed under special circumstances, the load power supply can be cut off by pressing the "emergency stop" button, and the "emergency stop" signal is input to the PLC.

(4) Limit protection In some cases where it is possible to produce danger if the hoist exceeds the limit, limit protection is set, and when the limit protection acts, the load power supply is directly cut off, and the signal is input to PLC.

Users can choose the appropriate relay type according to specific needs, and make flexible configuration and connection. High voltage and high current measurement: This module supports high voltage and high current measurement applications. It provides high-voltage and high-current input channels, can safely measure and control high-voltage and high-current signals, and is suitable for power, electronic equipment testing and control and other application fields. The powerful software support module is equipped with NI-DAQmx driver software, which provides rich functions and easy-to-use programming interface. Users can use LabVIEW, C/C++, Python and other common programming languages to program and control, and realize relay switch operation conveniently and quickly.
