IC695CHS016  背板  提供电源和信号分配功能

描述:IC695CHS016是一款PACSystem RX3i通用背板，以前由GE智能平台(GE IP)生产，现在属于艾默生自动化。该背板有12个插槽，支持安装基于pci的RX3i和系列90-30 I/O和可选模块。它有一个双母线背板，只支持水平安装方向。该背板具有隔离的24VDC输入和额定电流，在3.3 VDC为600 mA，在5 VDC为240 mA。

背板是一种电路板，通常用于连接和支持电子设备中的各种组件和模块。它是电子设备的重要组成部分，为设备的正常运行提供了必要的支持和连接。

IC695CHS016背板的主要功能是提供物理连接和电气连接，将各种组件和模块连接在一起，形成一个完整的系统。它通常包括各种插槽、接口和连接器，用于插入和连接各种电路板、模块、电缆和其他组件。

IC695CHS016背板还可以提供电源和信号分配功能，将电源和信号分配给各个组件和模块，以确保它们能够正常工作。

在电子设备中，IC695CHS016背板通常被安装在设备的背部或底部，并通过螺丝或其他固定装置固定在设备上。它通常由金属材料制成，以提供良好的机械强度和散热性能。

总之，IC695CHS016背板是电子设备中的重要组成部分，为设备的正常运行提供了必要的支持和连接。

IC695CHS016  背板  提供电源和信号分配功能

Description: The IC695CHS016 is a PACSystem RX3i universal backplane formerly manufactured by GE Intelligent Platforms (GE IP) and now owned by Emerson Automation. The backplane has 12 slots and supports the installation of PCI-based RX3i and series 90-30 I/O and optional modules. It has a dual bus backplane that supports horizontal mounting directions only. The backplane has an isolated 24VDC input and current rating of 600 mA at 3.3 VDC and 240 mA at 5 VDC.

A backplane is a circuit board commonly used to connect and support various components and modules in an electronic device. It is an important part of electronic equipment, providing the necessary support and connection for the normal operation of the device.

The main function of the IC695CHS016 backplane is to provide physical and electrical connections to connect various components and modules together to form a complete system. It typically includes various slots, interfaces, and connectors for inserting and connecting various circuit boards, modules, cables, and other components.

The IC695CHS016 backplane can also provide power and signal distribution functions, distributing power and signals to individual components and modules to ensure that they can work properly.

In electronic devices, the IC695CHS016 backplane is usually mounted on the back or bottom of the device and is secured to the device by screws or other fixtures. It is usually made of metallic materials to provide good mechanical strength and heat dissipation properties.

In short, the IC695CHS016 backplane is an important part of the electronic device, providing the necessary support and connectivity for the normal operation of the device.
