369-HI-R-M-0-0-0-E  电机管理继电器

莫迪林的 369-HI-R-M-0-0-0-E 旨在保护和控制电机及其随附组件。369通过各种内置功能实现这一目标，其中一些功能包括：

• 计量：369 可以监控电压、瓦特、频率和能量等量，根据生成的值数据生成保护功能。

• 活动记录：在旅行结束后，369能够报告旅行的原因，以及旅行时的温度和数据值，使用户能够分析系统中出了什么问题。

• 行前警报：369 可以在跳闸前通知用户，当它是由接地故障、机械卡纸、RTD 过热等引起的。

• 电机健康报告：继电器可以使用学习到的信息和系统跳闸历史记录来确定何时何地可能需要维护。

• 示波器：跳闸时触发三个波形记录，并捕获16个数据周期。在此过程中，会捕获相电流和接地电流以及触点输入状态。

369-HI-R-M-0-0-0-E 继电器生成的大量数据和保护功能有助于减少故障排除时间并延长系统寿命，使其成为中型电机的绝佳选择。

Modilin's 369-HI-R-M-0-0-0-E is designed to protect and control the motor and its accompanying components. 369 achieves this goal through various built-in features, some of which include:

Measurement: 369 can monitor quantities such as voltage, wattage, frequency, and energy, and generate protection functions based on the generated value data.

Activity record: After the trip, 369 can report the reason for the trip, as well as the temperature and data values during the trip, allowing users to analyze what problems have occurred in the system.

Pre travel alarm: 369 can notify users before tripping when it is caused by ground faults, mechanical paper jams, RTD overheating, etc.

Motor health report: Relays can use learned information and system trip history to determine when and where maintenance may be needed.

Oscilloscope: Triggering three waveform records during tripping and capturing 16 data cycles. During this process, phase current, ground current, and contact input status will be captured.

The extensive data and protection functions generated by the 369-HI-R-M-0-0-0-E relay help reduce troubleshooting time and extend system life, making it an excellent choice for medium-sized motors.
