可编程逻辑控制器 IS210BAPAH1A 设计用于管理蒸汽或燃气轮机

产品说明:GE IS210BAPAH1A PLCModule是一款高性能可编程逻辑控制器模块，专为工业自动化应用而设计。它提供了先进的功能和可靠性，以确保各种过程的有效和准确的控制。

产品参数:

-型号:IS210BAPAH1A

输入电压:24V DC

输出电压:24VDCMax

输入电流:1A- Max

输出电流:0.5A-

工作温度:-40°℃~70°℃-

通信协议:以太网、Modbus

该IS210BAPAH1A用作模拟处理器模块。它是 Mark VI 或 Mark VIe 系统的组件。这两个系统都来自GE，设计用于管理蒸汽或燃气轮机。Mark VI 采用中央控制设计，系统的核心是带有 13 槽或 21 槽 VME 卡架的中央控制模块。该平台可用于电源岛的集成和工厂控制的平衡。相反，Mark VIe是一个分布式控制系统，其控制处理通过节点分布在整个系统中。然后，这些节点将保持在中央调度程序的控制之下。

与 SAMB 端子板一起，IS210BAPAH1A构成了一个声学监听输入包。该套件支持框架 6/7/9 燃气轮机的动力学。 IS210BAPAH1A内置于一个狭窄的黑色外壳中，顶部和底部都有开口，以允许空气流动。后表面包括顶部和底部法兰，其表面刻有安装孔。前面板有一个插孔连接器和两组 LED 指示灯。

IS210BAPAH1A的配置和诊断可以通过 ToolboxST 应用程序运行。声学监测包可以计算 0 至 5000 Hz 频率范围内时域采样数据的宽带均方根 （RMS） 能量。它还可以取 RMS 扫描平均值和峰峰值扫描平均值。有关电池组、其安装和功能以及操作指南的更多信息，可以通过制造商出版物（用户指南/手册/数据表）找到。

可编程逻辑控制器 IS210BAPAH1A 设计用于管理蒸汽或燃气轮机

Product Description :GE IS210BAPAH1A PLCModule is a high-performance programmable logic controller module designed for industrial automation applications. It offers advanced features and reliability to ensure effective and accurate control of various processes.

Product parameters:

- Model :IS210BAPAH1A

Input voltage :24V DC

Output voltage :24VDCMax

Input current: 1A-Max

Output current :0.5A-

Operating temperature :-40° C ~70° C -

Communication protocol: Ethernet, Modbus

The IS210BAPAH1A is used as an analog processor module. It is a component of the Mark VI or Mark VIe system. Both systems come from GE and are designed to manage steam or gas turbines. The Mark VI has a central control design, and the core of the system is a central control module with a 13-slot or 21-slot VME bracket. The platform can be used for power island integration and plant control balance. In contrast, Mark VIe is a distributed control system whose control processing is distributed through nodes throughout the system. These nodes will then remain under the control of the central scheduler.

Together with the SAMB terminal board, the IS210BAPAH1A constitutes an acoustic listening input package. The kit supports the dynamics of the frame 6/7/9 gas turbine. The IS210BAPAH1A is built into a narrow black housing with openings at the top and bottom to allow air flow. The rear surface includes a top and bottom flange with mounting holes carved into the surface. The front panel has a jack connector and two sets of LED indicators.

Configuration and diagnostics for IS210BAPAH1A can be run through the ToolboxST application. The acoustic monitoring package calculates the broadband root-mean-square (RMS) energy of time-domain sampled data in the frequency range 0 to 5000 Hz. It can also take the RMS scan average and peak-to-peak scan average. More information about the battery pack, its installation and functions, and operating guidelines can be found through manufacturer publications (user guides/manuals/data sheets).
