DS3810MM GE 高效降压/升压转换器

输入电压范围：2.2V 至 5.5V

输出电压范围：1.8V 至 5.2V

运行和关断期间，I2C 可配置

VSEL 引脚用于在两个输出电压预设之间切换

输出电流

当 V我≥ 2.5V、V或 = 3.3V 时可达 2.5A

当 V我≥ 2.8V、V或 = 3.5V 时可达 2.5A

在整个负载范围内具有高效率

13µA 低工作静态电流

自动节电模式和强制 PWM 模式（I2C 可配置）

峰值电流降压/升压模式架构

可在降压、降压/升压和升压操作模式之间定义转换

正向和反向电流运行

启动至预偏置输出

安全、可靠运行 特性

集成软启动

过热和过压保护

关断期间的真正负载断开

正向和反向电流限制

两个器件选项

TPS63810：预编程输出电压（3.3V、3.45V）

TPS63811：启动前的程序输出电压

解决方案尺寸小于 20 mm2，仅有四个外部器件

DS3810MM 高效降压/升压转换器 完全可编程（通过 I2C）的高效率、高输出电流降压/升压转换器。 根据输入电压不同，当输入电压近似等于输出电压时，它们它会自动以升压、降压或全新的 4 周期降压/升压模式运行。

在定义的阈值内进行模式切换，避免不必要的模式内切换，以减少输出电压纹波。

两个可通过 I2C 访问的寄存器用于设置输出电压，VSEL 引脚用于选择哪个输出电压寄存器处于激活状态。 这样，这些器件就能够支持动态电压调节。 如果输出电压寄存器在运行过程中发生了更改或切换了 VSEL 引脚，则器件将以定义的可编程斜坡速率转换运行模式。

DS3810MM GE 高效降压/升压转换器

Input voltage range: 2.2V to 5.5V

Output voltage range: 1.8V to 5.2V

I2C can be configured during operation and shutdown

The VSEL pin is used to switch between two output voltage presets

Output current

It can reach 2.5A when V is ≥ 2.5V, V or = 3.3V

Up to 2.5A can be reached when V is ≥ 2.8V, V or = 3.5V

High efficiency over the entire load range

13µA low working static current

Automatic power saving mode and forced PWM mode (I2C configurable)

Peak current buck/boost mode architecture

Transitions can be defined between buck, buck/boost, and boost operating modes

Forward and reverse current operation

Boot to pre-biased output

Safe and reliable operation features

Integrated soft boot

Overheating and overvoltage protection

The true load is disconnected during shutdown

Forward and reverse current limits

Two device options

TPS63810: Pre-programmed output voltage (3.3V, 3.45V)

TPS63811: Program output voltage before startup

The solution is smaller than 20 mm2 and has only four external components

DS3810MM High efficiency buck/Boost converter Fully programmable (via I2C) High efficiency, high output current buck/boost converter. Depending on the input voltage, when the input voltage is approximately equal to the output voltage, they automatically operate in boost, buck, or a new 4-cycle buck/boost mode.

Mode switching within defined thresholds avoids unnecessary intra-mode switching to reduce output voltage ripple.

Two registers accessible via I2C are used to set the output voltage, and the VSEL pin is used to select which output voltage register is active. In this way, these devices can support dynamic voltage regulation. If the output voltage register is changed during operation or the VSEL pin is switched, the device will convert the operation mode at a defined programmable ramp rate.
