850-EP5NNG5HNNAANGAPFCSENNBN GE 控制板面

通电气Multilin (GE)

制造地点：加拿大安大略省万锦市

型号：850-EP5NNG5HNNAANGAPFCSENNBN

软件：能源维斯塔850

接地方向过流角精度：±20

过频拾音电平：20.00至65.00Hz，步长为0.01

RTD保护迟滞：2°℃

跳闸总线输入计数：16

产品描述

850-EP5NNG5HNNAANGAPFCSENNBN是由GE Mulilin为其850系列制造的图形控制面板。语言为英语。该控制面板在组5和组1中具有2安培三相电流输入。在Bank.3中，该面板没有相电流输入。接地电流为5安培接地输入。电源为110-250 VDC和110-230VAC。面板是彩色图形显示。电流保护是先进的。电压监控和保护也很先进。没有光纤连接器或无线通信。安全性是基本的。为了保护，曲线乘数为0.05至60000，步长为0.01。复位时间是定时和瞬时的。电流为相星或有效值。拾音水平为0.050至30.000 x CT，步长为0.001 x CT。

该图形控制面板包括CPU、模拟输入功能、频率测量、相星、瞬态、谐波、交流电流输入处理和保护元件。其他器件功能包括自动总线传输方案、断路器电弧电流、断路器控制、断路器健康、冷负载拾取、输出继电器、需求、数字计数器、事件记录器、故障报告和故障定位器、FlxLogic公式、IEC 61850通信、负载侵占、手动闭合阻塞、计量(电流、功率、电压、能量、PF、谐波、频率、THD)、Modbus用户图、非易失性锁存器、6个设定点组、6个跳闸总线、一个瞬态记录器(示波器)、跳闸和闭合线圈监控、欠频恢复、欠压恢复、用户可编程LED、用户可编程按钮、32个虚拟输入和32个虚拟输出。

控制面板的功能和作用

控制面板提供了许多实用的功能和作用，包括以下几个方面:

1.系统设置

控制面板提供了许多系统设置选项，例如调整屏幕分辨率、修改主题样式、设置音量等等。这些系统设置选项可根据用户的需求进行调整，从而让计算机的显示效果、音效和其他设置符合用户的喜好和需求。

2.设备和硬件管理

在控制面板中，用户可以轻松管理和维护计算机上的硬件和设备，例如打印机、摄像头、键盘、鼠标等。用户可以进行设备的添加、删除、故障排查等操作，还可以根据需要对硬件进行升级、更新等操作。

关于850-EP5NNG5HNNAANGAPFCSENNBN的常见问题

850 GE Multilin系列创新的馈线保护系统有哪些应用? 850-EP5NNG5HNNAANGAPFCSENNBN有哪些特点?

850-PSNNGHNNANGAFCSENBN是Multilin 850系列馈线保护系统的成员。这些850继电器设计用于为工业或配电网络的架空或地下中压馈线提供保护(备用或初级)。Mutilin850具有灵活

的配置功能，能够提供高性能保护和可编程逻辑功能。该供料器保护继电器系统提供的好处是减少供料器停机时间、访问环境诊断信息、简化测试时间以及增加过程正常运行时间。

850-EP5NNG5HNNAANGAPFCSENNBN GE 控制板面

Multilin (GE)

Manufacturing Location: Markham, Ontario, Canada

Model: 850-EP5NNG5HNNAANGAPFCSENNBN

Software: Energy Vista 850

Ground direction overcurrent Angle accuracy: ±20

Overfrequency pickup level: 20.00 to 65.00Hz, step size is 0.01

RTD protection lag: 2° C

Trip bus input count: 16

Product description

The 850-EP5NNG5HNNaangapFCSENNBN is a graphic control panel manufactured by GE Mulilin for its 850 series. The language is English. The control panel has a 2 amp three-phase current input in groups 5 and 1. In Bank.3, the panel has no phase current input. The ground current is 5 amps ground input. Power supply is 110-250 VDC and 110-230VAC. The panel is a color graphic display. Current protection is advanced. Voltage monitoring and protection are also advanced. No fiber optic connectors or wireless communications. Security is fundamental. For protection, the curve multiplier is 0.05 to 60,000 and the step size is 0.01. The reset time is timed and instantaneous. The current is either phase star or effective value. The pickup level is 0.050 to 30.000 x CT and the step size is 0.001 x CT.

The graphical control panel includes CPU, analog input function, frequency measurement, phase star, transient, harmonic, AC current input processing, and protection elements. Additional device features include automatic bus transfer schemes, circuit breaker arc current, circuit breaker control, circuit breaker health, cold load pickup, output relays, requirements, digital counters, event loggers, fault reporting and fault locators, FlxLogic formulas, IEC 61850 Communication, load overrun, manual closure blocking, metering (current, power, voltage, energy, PF, Harmonics, frequency, THD), Modbus user chart, non-volatile latches, 6 set points, 6 trip buses, a transient recorder (oscilloscope), trip and closure coil monitoring, underfrequency recovery, undervoltage recovery, user programmable L ED, user programmable buttons, 32 virtual inputs and 32 virtual outputs.

Function and role of control panel

The control panel provides many practical functions and roles, including the following:

1. Set the system

The Control panel provides many system Settings options, such as adjusting the screen resolution, modifying the theme style, setting the volume, and more. These system Settings options can be adjusted according to the needs of the user, so that the computer's display, sound, and other Settings match the user's preferences and needs.

2. Device and hardware management

In the Control panel, users can easily manage and maintain the hardware and devices on the computer, such as printers, cameras, keyboards, mice, etc. You can add, delete, and troubleshoot devices. You can also upgrade or update hardware as required.

Frequently Asked Questions about 850-EP5NNG5HNNAANGAPFCSENNBN

What are the applications for the innovative feeder protection systems of the 850 GE Multilin series? 850-EP5NNG5HNNAANGAPFCSENNBN What are the features of NBN?

The 850-PSNNGhnNangafcSENbn is a member of the Multilin 850 series feeder protection system. These 850 relays are designed to provide protection (standby or primary) for overhead or underground medium voltage feeders in industrial or distribution networks. The Mutilin850 is flexible

Provides high-performance protection and programmable logic functions. The feeder protection relay system provides benefits such as reduced feeder downtime, access to environmental diagnostic information, simplified test time, and increased process uptime.
