IC693ACC310 平台附件模块

IC694ACC310是系列90-30可编程逻辑控制器(PLC)平台附件模块。该模块在技术上称为填充模块,有时也称为槽位填充模块或假模块。该元件主要用于覆盖90-30系列底板的空槽,保护电子电路免受灰尘、污垢、油、水、化学和其他工业元素的损坏。


IC694ACC310占用机箱单槽位。它支持在电源下拆卸和插入,因为这个填充模块不连接到背板,因为它不携带任何电子电路,但是,在经常暴露于振动和冲击的旧装置中,应小心插入和拆卸。


联系电话:18059884797

产品详情

IC693ACC310 平台附件模块








【功能描述】

IC694ACC310是系列90-30可编程逻辑控制器(PLC)平台附件模块。该模块在技术上称为填充模块,有时也称为槽位填充模块或假模块。该元件主要用于覆盖90-30系列底板的空槽,保护电子电路免受灰尘、污垢、油、水、化学和其他工业元素的损坏。


IC694ACC310占用机箱单槽位。它支持在电源下拆卸和插入,因为这个填充模块不连接到背板,因为它不携带任何电子电路,但是,在经常暴露于振动和冲击的旧装置中,应小心插入和拆卸。


IC694ACC310可安装在安装CPU的本地背板上;扩展背板,远程背板或沿网络接口模块(NIU)的分布式I/O站。IC694ACC310的安装实例数量没有限制。它可以根据需要和控制系统的要求使用。


IC694ACC310的物理尺寸与功能齐全的模块相似,但是,由于该组件没有LED状态指示灯和模块插入,因此无法使用监控功能和模块I/O标记。


将IC694ACC310安装到系列90-30底板上时,请将IC694ACC310直接对准空槽的顶部,并沿相邻模块的边缘对齐。轻轻推动模块并按压,直到顶部和底部闩锁连接到底板上。


IC693ACC310模块是GE发那科90-30系列的填充模块。关于GE发那科IC693ACC310填充模块的一个值得注意的事情是,它与GE发那科系列90-30可编程逻辑控制器产品线中的各种plc或可编程逻辑控制器兼容。当使用该产品线中的一个plc时,模块底板中的一些I/O插槽在控制器的应用程序中将是冗余的,除非安装了IC693ACC310填充模块,否则它们将为空。假模块可以防止灰尘进入CHS机架的连接器。在使用过程中,为了防止灰尘进入组件内部,必须确保底板中所有未使用的槽位都被填充,这些槽位可以使用有源设备或模块填充,也可以使用空白的填充模块填充,如GE Fanuc IC693ACC310填充模块。


GE Fanuc系列90-30 IC693ACC310填充模块的设计易于使用,这意味着技术人员不需要大量的技术知识就可以正确安装。

IC693ACC310 平台附件模块




 The IC694ACC310 is a series 90-30 Programmable Logic Controller (PLC) platform accessory module. This module is technically called as a filler module, sometimes also referred as slot filler or dummy module. This component is mainly used to cover a vacant slot of a series 90-30 baseplate and protect the electronic circuitry from the damage due to exposure to dust, dirt, oil, water, chemical and other industrial elements.

The IC694ACC310 occupies a single slot of the chassis. It supports removal and insertion under power as this filler module does not connect to the backplane as it does not carry contain any electronic circuitry however, in old installations that are regularly exposed to vibration and shock, careful insertion and removal should be observed.

The IC694ACC310 can be installed in the local backplane where the Central Processing Unit (CPU) is installed; to an expansion backplane, a remote backplane or distributed I/O station along a Network interface Module (NIU). There is no limit to the number of installation instances of the IC694ACC310. It may be used as needed and as required by the control system.

The IC694ACC310 physical dimensions is similar to fully functional modules however, the monitoring features and module I/O tagging is not available to this component as it does not come with LED status indicator and a module insert.

To install the IC694ACC310 to a Series 90-30 baseplate, align the module directly on top of the vacant slot and along the edges of the adjacent module. Slightly push the module and press until the top and bottom latch attached to the baseplate.

The IC693ACC310 module is a filler module manufactured by GE Fanuc in Series 90-30. One notable thing about the IC693ACC310 filler module by GE Fanuc is that it is compatible with a wide range of PLCs or Programmable Logic Controllers which are in the GE Fanuc Series 90-30 Programmable Logic Controllers product line. When using one of the PLCs in this product line, some of the I/O slots in the modules baseplates will be redundant in the controller’s applications and they will be left empty unless a filler module like the IC693ACC310 filler module is installed. The filler module prevents dust from entering the connectors at the CHS racks. It is essential to ensure that all the unused slots in the baseplates are filled during applications to prevent dust from entering the components, and they can be filled by active devices or modules or a blank filler module like the GE Fanuc IC693ACC310 filler module.

The GE Fanuc Series 90-30 IC693ACC310 filler module is designed to be easy to uses, which means that technicians do not need a lot of technical knowledge to install it properly.
