IS200BPVCG1BR1 该板的后半部分有21个母背板连接器

IS200BPVCG1BR1是通用电气Mark VI系列中使用的PCB组件。Mark VI系列是后来的Speedtronic系统之一。GE花了30多年的时间研究和开发Speedtronic系统，为重型蒸汽和燃气轮机系统的管理创造了一个可靠、可扩展、完整的解决方案。Mark VI使用最新的技术和集成的专有软件来创建最佳的涡轮机管理系统。这包括一个基于pc的HMI(操作界面)，它运行通用电气的simplicity图形等软件。

联系电话：18059884797

立即咨询在线留言

产品详情

IS200BPVCG1BR1 该板的后半部分有21个母背板连接器

【功能描述】

IS200BPVCG1BR1是一款背板，设计用于接受和支持多板的机架系统。该板的后半部分有21个母背板连接器。当放置在机架系统，这部分板将被包围的高墙，将支持和锁定连接板到位。电路板的另一部分，它持有输入/输出连接器，被设计为暴露在机架系统之外。这使得操作员可以轻松地将带状连接器及其电缆连接到电路板。有39个I/O连接器，允许数据从连接到背板的板之间传输。IS200BPVCG1BR1还包括14个插接连接器和6个电阻网络阵列。在电路板的底部还有另外30个元件。它们被标记为L1到L30。电路板上标有制造商标志和板号。

IS200BPVCG1BR1 该板的后半部分有21个母背板连接器

The IS200BPVCG1BR1 is a PCB component used in the Mark VI series from GE. The Mark VI series is one of the later Speedtronic systems. GE has spent over three decades researching and developing the Speedtronic system to create a reliable, scalable, complete solution to the management of heavy-duty steam and gas turbine systems. The Mark VI uses more recent technology and integrated proprietary software to create an optimal turbine management system. This includes a PC-based HMI (operator interface) that runs software like General Electric’s CIMPLICITY graphics.

The IS200BPVCG1BR1 is a backplane board that has been designed to fit into a rack system that accepts and supports multiple boards. The rear half of this board is populated with twenty-one female backplane connectors. When placed in the rack system, this part of the board will be surrounded by tall walls that will support and lock connecting boards into place. The other part of the board, which holds Input/Output connectors, is designed to be left exposed outside the rack system. This allows the operator to easily connect ribbon connectors and their cabling to the board. There are thirty-nine I/O connectors, which allow data transfer from and to the boards attached to the backplanes. The IS200BPVCG1BR1 also includes fourteen stab-on connectors and six resistor network arrays. There are an additional thirty components on the bottom side of the board. These are labeled L1 through L30. The board is marked with the manufacturer logo and with the board number.
