IS420YAICS1B 处理多达10个模拟输入

IS420YAICS1B技术规格

手册geh -6855卷一、二

处理器板bppc

功耗5.3瓦典型

部件编号is420yaics1b

制造商通用电气

环境温度范围-40至158°F

输入转换器分辨率16位ADC

功能缩写yaic

尺寸:高3.25英寸x宽1.65英寸x深4.78英寸

ControlST软件套件版本v06.01及后续版本

兼容固件v05.01或更高版本

联系电话：18059884797

立即咨询在线留言

产品详情

IS420YAICS1B 处理多达10个模拟输入

【功能描述】

模拟I/O包IS420YAICS1B是通用电气生产的Mark VIe系列的一部分。这个I/O包可以在两个以太网网络和一个终端模拟I/O板之间进行接口。该包可以处理多达10个模拟输入，其中两个可以配置为±1 mA或4-20 mA电流输入，而其余8个是±5 V或±10 V输入，或4-20 mA电流回路输入。该包可以通过双RJ45以太网连接器发送和接收数据。

虽然Mark VIe系列中的各种单元可用于双路、TMR或单工冗余应用程序，但IS420YAICS1B I/O包只能用于TMR或单工冗余应用程序，请注意，在TMR冗余应用程序中使用此包时，将使用三个I/O包，而在单工冗余应用程序中只使用一个I/O包。另一个重要的注意事项是，TMR集中的所有I/O包必须采用相同的硬件形式。还有一个版本的YAIC I/O包，标签是IS420YAICS1A包，请注意，包版本不能混合在同一个t型端子板上。

IS420YAICS1B I/O包可以执行几个自诊断测试，其中一些是上电自检，将检查闪存和RAM内存、大多数处理器板硬件和包上的以太网端口。该包还可以连续监控内部电源，以确保正确的操作。

IS420YAICS1B 处理多达10个模拟输入

The analog I/O package IS420YAICS1B is part of the Mark VIe series produced by General Electric. This I/O packet can interface between two Ethernet networks and a terminal analog I/O board. The package can handle up to 10 analog inputs, two of which can be configured as ±1 mA or 4-20 mA current inputs, while the remaining eight are ±5 V or ±10 V inputs, or 4-20 mA current loop inputs. The packet can send and receive data via dual RJ45 Ethernet connectors.

While the various units in the Mark VIe series can be used for dual-way, TMR, or simplex redundant applications, the IS420YAICS1B I/O package can only be used for TMR or simplex redundant applications, and note that when using this package in TMR redundant applications, three I/O packages will be used. In a simplex redundant application, only one I/O package is used. Another important note is that all I/O packages in a TMR set must be in the same hardware form. There is also a version of the YAIC I/O package labeled IS420YAICS1A package, please note that the package versions cannot be mixed on the same T-terminal board.

The IS420YAICS1B I/O package can perform several self-diagnostic tests, some of which are power-on self-tests that will check flash and RAM memory, most processor board hardware, and Ethernet ports on the package. The package can also continuously monitor the internal power supply to ensure proper operation.
