IS200SRTDH2ACB GE 印刷电路板

【功能描述】

IS200SDIIH1ADB MRP683026是由通用电气或GE创建的印刷电路板或PCB，是Mark VI系列的一部分。马克六是最新版本的马克阵容由通用电气。马克六世和马克家族的其他系列是为了管理和自动化燃气和蒸汽轮机系统的过程而开发的。这些在全球许多不同的行业中都得到了应用。

IS200SDIIH1ADB MRP683026是一个相对较小的印刷电路板，电子元件的尺寸不等。两(2)个大型端子排位于IS200SDIIH1ADB MRP683026的底边，一个在另一个的上面。每个端子排包含十八(18)个端子，总共有三十六(3)个端子。这些包含在端子排内的银色金属端子用白色书写从1(1)到36(36)编号。IS200SDIIH1ADB MRP683026的上边界附有一个(1)大连接器端口。该接口用于将额外的组件或其他单板连接到IS200SDIIH1ADB MRP683026上。IS200SDIIH1ADB MRP683026的中心被一组二极管和电容器占据。二极管的形状像黑色矩形。有24个二极管，它们被分成两(2)行，每行12个二极管。每个二极管旁边都有一个(1)或两个(2)矩形小电容器。IS200SDIIH1ADB MRP683026的左上角已经打印了设备的完整部件名称IS200SDIIH1ADB MRP683026。GE的标志已经印在这个零件号下面的板上。

IS200SDIIH1ADB MRP683026 is a printed circuit board or PCB created by General Electric or GE and is part of the Mark VI series. The Mark VI is the latest version of the Mark lineup by General Electric. The Mark VI and other series of the Mark family were developed to manage and automate the processes of gas and steam turbine systems. These are used in many different industries around the world.

The IS200SDIIH1ADB MRP683026 is a relatively small printed circuit board with electronic components of varying sizes. Two (2) large terminal blocks are located on the base edge of the IS200SDIIH1ADB MRP683026, one on top of the other. Each terminal block contains eighteen (18) terminals for a total of thirty-six (3) terminals. These silver metal terminals contained within the terminal block are numbered in white writing from 1(1) to 36(36). The IS200SDIIH1ADB MRP683026 has a (1) large connector port attached to its upper border. This interface is used to connect additional components or other boards to the IS200SDIIH1ADB MRP683026. The center of the IS200SDIIH1ADB MRP683026 is occupied by an array of diodes and capacitors. The diode is shaped like a black rectangle. There are 24 diodes, which are divided into two (2) rows of 12 diodes per row. Next to each diode is one (1) or two (2) rectangular small capacitors. IS200SDIIH1ADB MRP683026 The full part name of the device IS200SDIIH1ADB MRP683026 has been printed in the upper left corner. The GE logo is already printed on the board below this part number.
