通用电气(GE)创建了IS200TREAH2AED作为行程紧急终止板。这是一种为Mark VI系列制作的印刷电路板或PCB。Mark VI是通用电气Mark系列的最新系列。这些系列是为蒸汽和燃气轮机的操作和自动化而制造的。

这个装置上最引人注目的部件是一系列方形的变压器。这些变压器由透明塑料和银线覆盖。这些包括有关部件的特征信息，如部件号和电压。在IS200TREAH2AED上有十二(12)个这样的变压器，在两条竖线上各有六(6)个变压器。在IS200TREGH1B的左边缘有两个大的黑色端子排。端子组共包含由银金属制成的48个端子。这些终端在两(2)个终端之间平均分配为每个24个。IS200TREAH2AED包含许多称为金属氧化物压敏电阻或MOVs的组件。这些运动是圆形和纯红色的。它们被放置在IS200TREAH2AED的边缘。三(3)白色跳线端口已放置在IS200TREAH2AED的顶部边缘。这些端口之间总共有17个端口。左边的连接器有三个端口，标识为JH1。中间的连接器包含12个标识为J2的端口，右边的最后一个连接器具有两(2)个标识为J1的端口。

IS200TREAH2AED GE 作为行程紧急终止板

General Electric (GE) created the IS200TREAH2AED as a trip emergency termination board. This is a printed circuit board or PCB made for the Mark VI series. The Mark VI is the latest in the General Electric Mark series. These series are manufactured for the operation and automation of steam and gas turbines.

The most striking part of the device is a series of square transformers. These transformers are covered with transparent plastic and silver wire. These include characteristic information about the part, such as part number and voltage. There are twelve (12) such transformers on the IS200TREAH2AED, and six (6) transformers on each of the two vertical lines. There are two large black terminal blocks on the left edge of the IS200TREGH1B. The terminal group consists of 48 terminals made of silver metal. These terminals are evenly divided between two (2) terminals to 24 each. The IS200TREAH2AED contains a number of components called metal oxide varistors or MOVs. These movements are round and pure red. They are placed on the edge of the IS200TREAH2AED. Three (3) white jumper ports have been placed on the top edge of the IS200TREAH2AED. There are a total of 17 ports between these ports. The connector on the left has three ports, identified as JH1. The middle connector contains 12 ports identified as J2, and the last connector on the right has two (2) ports identified as J1.
