DS200DSPCH1ADA GE 远程扩展器模块

 DS200DSPCH1ADA  GE 远程扩展器模块

DS200DSPCH1ADA 是具有多个子板的复杂电路板

DS200DSPCH1ADA 是一款 GE 数字信号处理器控制板，与用于蒸汽和燃气工业涡轮机的 GE Mark V Speedtronic 控制系统兼容。DS200DSPCH1ADA 提供通信带宽和处理能力，可直接控制系统的电源转换器应用和高性能驱动器。该板内置可扩展的输入和输出。

DS200DSPCH1ADA 是具有多个子板的复杂电路板。一块板使用支架与板表面平行安装，另一块板垂直安装。其中一个子板用于提供信号的缩放、缓冲、隔离和调节，以便 DS200DSPCH1ADA 的数字信号处理器可以访问和使用它们。

DS200DSPCH1ADA 的后缘有两个背板连接器。该板带有一个带有多种 I/O 和 LED 指示灯的附加前面板。面板还有一个复位按钮和两个固定螺钉（顶部和底部），有助于在将板安装到机架系统中时将其锁定到位。更换电路板时，请确保首先从驱动器上移除所有电源。不正确的安装程序可能会导致人身伤害。

 DS200DSPCH1ADA  GE 远程扩展器模块

DS200DSPCH1ADA is a complex circuit board with multiple daughter boards.

DS200DSPCH1ADA is a GE digital signal processor control board, which is compatible with the GE Mark V Speedtronic control system for steam and gas industrial turbines. DS200DSPCH1ADA provides communication bandwidth and processing power, which can directly control the power converter application and high-performance driver of the system. The board has built-in extensible input and output.

DS200DSPCH1ADA is a complex circuit board with multiple daughter boards. One board is installed parallel to the board surface with a bracket, and the other board is installed vertically. One of the daughter boards is used to provide scaling, buffering, isolation and adjustment of signals, so that the digital signal processor of DS200DSPCH1ADA can access and use them.

There are two backplane connectors at the rear edge of DS200DSPCH1ADA. The board has an additional front panel with various I/O and LED indicators. The panel also has a reset button and two fixing screws (top and bottom) to help lock the board in place when it is installed in the rack system. When replacing the circuit board, make sure to remove all power supplies from the drive first. Incorrect installation procedures may cause personal injury.
