GE IC693CPU374  处理器模块

IC693CPU374是GE发那科可编程逻辑控制器（PLC）的90-30系列模块。该模块是一个处理器模块，用于托管用户程序，通过嵌入式通信端口执行与处理器之间的逻辑和托管数据交换。

IC693CPU374也可以称为控制器。该控制器内置微处理器和嵌入式 586 处理器，处理速度为 133 MHz。它的典型扫描速率为每 0K 布尔接触逻辑 15.1 毫秒。该控制器模块具有安装在 90-30 PLC 机架上的单个插槽宽度。

IC693CPU374的用户存储器为240KB。它具有两 （2） 个以太网通信端口，支持 10/100 Mbps 的传输速度，具有自动感应功能。这些端口使控制器能够连接到以太网，以便与台式机或笔记本电脑等编程工作站进行通信，与人机界面（HMI）和监控与数据采集（SCADA）系统以及用于消息传递功能的其他处理器进行通信。该控制器也可以通过RS485通信接口进行通信，该接口可以在标准或大容量电源的电源上找到。

IC693CPU374 is a 90-30 series module of GE FANUC Programmable logic controller (PLC). This module is a processor module used to host user programs and perform logical and managed data exchange with the processor through embedded communication ports.

IC693CPU374 can also be referred to as a controller. The controller is equipped with a built-in microprocessor and an embedded 586 processor, with a processing speed of 133 MHz. Its typical scanning rate is 15.1 milliseconds per 0K Boolean contact logic. This controller module has a single slot width installed on a 90-30 PLC rack.

The user memory of IC693CPU374 is 240KB. It has two (2) Ethernet communication ports, supports a transmission speed of 10/100 Mbps, and has automatic sensing function. These ports enable the controller to connect to Ethernet for communication with programming workstations such as desktops or laptops, as well as with human machine interfaces (HMI) and monitoring and data acquisition (SCADA) systems, as well as other processors used for messaging functions. The controller can also communicate through the RS485 communication interface, which can be found on standard or high-capacity power supplies.
