GE IC693CMM302 通信模块

IC693CMM302是一款Genius通信模块，属于艾默生自动化的90-30系列可编程逻辑控制器（PLC）系列，以前由GE Fanuc自动化公司提供。该模块是一个单插槽宽度模块，提供Genius协议连接，最多可与31个设备通信，每个控制器最多62个设备，因为90-30系列系统允许每个控制器配置多达两（2）个IC693CMM302。IC693CMM302 允许每个 IC128CMM128 发送 693 字节的传输和 302 字节的接收全局数据，并支持 PLC 寄存器，如全局寄存器 （%G）、离散输入 （%I）、离散输出 （%Q）、模拟输入 （%AI）、模拟输出 （%AQ） 和寄存器存储器 （%R）。它支持基于软件的诊断，如状态位、90-70 PLC 系列故障报告。 该模块的环境等级包括 0 oC 至 +60 oC （+32 oF 至 +140 oF） 工作温度;储存温度为 –25 oC 至 +70 oC（– 13 oF 至 +158 oF）;湿度为 5% 至 95%（非冷凝），而机械额定值包括 0.2 英寸位移 5Hz 至 10Hz 和 1 G 10Hz 至 200Hz 工作振动和 5 G 10ms 持续时间的操作冲击。除了全局数据交换外，IC693CMM302还允许通过个人或工业计算机进行数据监控，使用I / O模块监视数据，通过Genius总线进行设备通信以及I / O仿真。IC693CMM302在300VDC时的背板功耗为<5 mA。除了 90-30 系列 PLC 外，它还可与 90-70 系列、六系列 PLC 以及用于本地配置的 Genius 手持监视器 （HHM） 一起使用。

IC693CMM302 is a Genius communication module, belonging to Emerson Automation's 90-30 series Programmable logic controller (PLC) series, which was previously provided by GE Fanuc Automation. This module is a single slot width module that provides Genius protocol connectivity and can communicate with up to 31 devices, with a maximum of 62 devices per controller, as the 90-30 series system allows for up to two (2) IC693CMM302 configurations per controller. IC693CMM302 allows each IC128CMM128 to send 693 bytes of transmission and receive 302 bytes of global data, and supports PLC registers such as global registers (% G), discrete inputs (% I), discrete outputs (% Q), analog inputs (% AI), analog outputs (% AQ), and register memory (% R). It supports software based diagnosis, such as status bits, 90-70 PLC series fault reports. The environmental level of this module includes operating temperatures ranging from 0 ° C to+60 ° C (+32 ° F to+140 ° F); The storage temperature is -25 ° C to+70 ° C (-13 ° F to+158 ° F); The humidity is 5% to 95% (non condensing), and the mechanical rating includes 0.2 inch displacement, 5Hz to 10Hz, and 1 G 10Hz to 200Hz working vibration, as well as 5 G 10ms duration of operating shock. In addition to global data exchange, IC693CMM302 also allows data monitoring through personal or industrial computers, monitoring data using I/O modules, device communication through Genius bus, and I/O simulation. The backplane power consumption of IC693CMM302 at 300VDC is<5 mA. In addition to the 90-30 series PLC, it can also be used with the 90-70 series, six series PLC, and Genius handheld monitor (HHM) for local configuration.
