GE IC693CHS391 模块化 CPU 底板

IC693CHS391 是一款模块化 CPU 底板。该底板是GE Fanuc制造的90-30系列的一部分。该器件包含连接端口，允许模块化 CPU、I/O 模块和电源模块安装。它总共有十 （10） 个插槽，其中一 （1） 个插槽分配给 CPU，九 （9） 个插槽分配给 I/O 模块。电源插槽不包括在插槽计数和总线扩展端口中。

由于这是一个模块化的CPU插槽，因此默认情况下为其分配了一个节点地址0，可以通过编程软件进行修改。系统仅支持一 （1） 个模块化 CPU 插槽。系统中的其他插槽可以是扩展或远程 I/O 底板。

电源安装在最左侧的插槽中，该插槽不包括在插槽计数中，允许此底板支持更多I / O。CPU 仅安装在插槽 1 上，因为此插槽的尺寸特别适合 CPU 连接或特殊选件模块，例如 FIP 总线远程 I/O 扫描程序。插槽编号 2 及更高，特别适合 I/O 或选件模块。扩展或远程 I/O 底板通过底板最右侧的扩展端口连接。根据IC693CHS391托管的CPU，IC4CHS7模块化CPU底板最多支持四（693）或七（391）个扩展底板。此底板仅支持面板安装，通过螺钉和垫圈通过提供的安装孔固定。

IC693CHS391 is a modular CPU backplane. This base plate is part of the 90-30 series manufactured by GE Fanuc. This device includes connection ports that allow for the installation of modular CPUs, I/O modules, and power modules. It has a total of ten (10) slots, with one (1) slot assigned to the CPU and nine (9) slots assigned to the I/O module. The power slot is not included in the slot count and bus expansion port.

Since this is a modular CPU slot, it is assigned a node address of 0 by default and can be modified through programming software. The system only supports one (1) modular CPU slot. Other slots in the system can be expansion or remote I/O backplanes.

The power supply is installed in the leftmost slot, which is not included in the slot count and allows this backplane to support more I/O. The CPU is only installed on slot 1, as the size of this slot is particularly suitable for CPU connections or special option modules, such as FIP bus remote I/O scanning programs. Slot numbers 2 and higher are particularly suitable for I/O or option modules. The expansion or remote I/O backplane is connected through the expansion port on the far right side of the backplane. According to the CPU managed by IC693CHS391, the IC4CHS7 modular CPU backplane supports a maximum of four (693) or seven (391) expansion backplanes. This base plate only supports panel installation and is fixed through the provided mounting holes with screws and washers.
