GE WES5123-1200 模块化通信设备

GE   WES5123-1200   模块化通信设备PROM模块安装在GE Genius适配器板WES5123-1200上的连接器中，并且由于它们是可拆卸的，因此更换板更容易，因为您无需重新配置更换板。您需要做的就是将PROM模块从旧板移动到替换板。但是，PROM 模块对静电积聚很敏感，静电积聚会损坏模块并擦除模块上的信息。腕带可保护PROM模块免受静电积聚的影响，因为它为静电提供了接地路径,静电由连接到腕带的未上漆金属表面提供。GE   WES5123-1200   模块化通信设备处理GE天才适配器板WES5123-1200时始终佩戴腕带。该板长6英寸,高1.25英寸,四个角各有一-个孔。更换旧主板时,请注意旧主板在驱动器机架中的连接位置,并计划将更换主板连接到同-位置。两只手拧下旧盘子。用一只手将螺丝刀的末端引导到第一个螺钉上。 服一只手转动螺丝刀。保留用于固定旧板的所有垫圈和螺钉，并使用它们来连接替换板。GE   WES5123-1200   模块化通信设备

The GE WES5123-1200 modular communication device PROM modules are installed in connectors on the GE Genius adapter board WES5123-1200, and since they are detachable, board replacement is easier because you do not need to reconfigure the replacement board. What you need to do is move the PROM module from the old board to a replacement board. However, the PROM module is sensitive to static electricity accumulation, which can damage the module and erase information on the module. The wrist strap can protect the PROM module from the accumulation of static electricity, as it provides a grounding path for static electricity, which is provided by the unpainted metal surface connected to the wrist strap. The GE WES5123-1200 modular communication device always wears a wrist strap when handling the GE genius adapter board WES5123-1200. The board is 6 inches long and 1.25 inches high, with one to one hole at each of its four corners. When replacing an old motherboard, please pay attention to the connection position of the old motherboard in the drive cage and plan to connect the replacement motherboard to the same location. Twist off the old plate with both hands. Guide the end of the screwdriver onto the first screw with one hand. Turn the screwdriver with one hand. Retain all washers and screws used to secure the old board and use them to connect the replacement board. GE WES5123-1200 Modular Communication Equipment
