IS200JPDHG1AAA  | 电源模块   |  为 I/O 包提供更多的电源

产品描述

IS200JPDHG1AAA型号作为高密度配电卡销售，通常用于 Mark VI 系列。当该装置运行时，它可以向多达三个以太网交换机以及 24 个 Mark VIe I/O 组发出 28 伏直流电。 如果需要，可以购买更多的 JPDH 包，然后连接在一起，为 I/O 包提供更多的电源。请注意，当将更多 JPDH 卡连接在一起时，它们必须以菊花链排列方式连接。

该板的物理组件是 29 个母针插头连接器。其中 29 个是 6 针连接器，其余 27 个连接器是 2 针连接器;其中 24 个连接器分为三排，每排 8 个。这些行中的连接器标记为 JT1 到 JT8、JR1 到 JR8 以及 JS1 到 JS8。这些行是将主电源提供给独立 I/O 包的馈电。I/O 包电路将包括一个温度系数保险丝装置，该保险丝欺骗将用于分支电路保护并提供正温度保险丝。

在许多危险场所可以使用IS200JPDHG1AAA板。可以使用此板的主要位置是 ATEX 2 区 IIC 组、I 类 2 区 A 至 D 组和 I 类 2 区 IIC 组。该板也可用于非危险场所，ULE207685在非危险场所使用的认证代码。

JPDH 型号非常适合菊花链连接，为 Mark VIe I/O 电池组提供更多功率，但需要注意的是，将多个 JPDH 型号连接在一起时，必须使用分支电路保护。- AX控制技术员

Product description

The IS200JPDHG1AAA model is marketed as a high density power distribution card and is commonly used in the Mark VI series. When the unit is operating, it can send 28 volts of direct current to up to three Ethernet switches as well as 24 Mark VIe I/O groups. If needed, you can buy more JPDH packages and then connect them together to provide more power to the I/O packages. Note that when connecting more JPDH cards together, they must be connected in a Daisy chain arrangement.

The physical components of the board are 29 female pin plug connectors. 29 of them are 6-pin connectors, and the remaining 27 connectors are 2-pin connectors; The 24 connectors are divided into three rows of eight connectors each. The connectors in these rows are labeled JT1 to JT8, JR1 to JR8, and JS1 to JS8. These lines are the feeds that provide the main power to individual I/O packets. The I/O packet circuit will include a temperature coefficient fuse device, which will be used to protect the branch circuit and provide a positive temperature fuse.

The IS200JPDHG1AAA board can be used in many hazardous places. The main locations where this board can be used are ATEX Zone 2 IIC Group, Class I Zone 2 A to D Group, and Class I Zone 2 IIC Group. The board can also be used in non-hazardous places, ULE207685 certification code for use in non-hazardous places.

JPDH models are ideal for Daisy chain connections to provide more power to the Mark VIe I/O battery pack, but it is important to note that branch circuit protection must be used when connecting multiple JPDH models together. - AX control Technician
