DS200CDBAG1B  |  驱动器控制板  | 可提供协调接触器操作

规格

产品编号： DS200CDBAG1A

制造商： General Electric

系列： 驱动器控制

功能说明： 接触器驱动板

保险丝： 4 amp 125V

测试点： 3

DS200CDBAG1B 印刷电路板组装中列出的三个测试点中的每一个都通过其工厂印刷的命名标签、测试点编号以及 DS200CDBAG1B 板及其更大的 Mark V 涡轮控制系统系列自动驱动组件的特定预期功能的组合来命名。DS200CDBAG1B板是第二组CDBA型号的一部分。G1B 版本可提供协调接触器操作，JP2 用于协调操作，LED1 在电路板选择协调模式时提供状态信息。JP2 的位置必须能够控制 1TB-9 和 1TB-10 输入，以便它们可以同步操作接触器。

当 JP2 设置正确时，它允许启用固态开关;该开关还将打开 1TB-1 和 1TB-1 输入，并为 1TB-9 和 1TB-10 输入通电，以便它们可以继续为接触器通电。以上所有信息均来自 GEI-100182B 接触器驱动板使用说明书。GEI-100182B手册包含有关DS200CDBAG1B板电位计、可配置跳线、故障排除、安装等信息。在对这款DS200CDBAG1B产品做出任何最终购买决定之前，最重要的是要了解这款DS200CDBAG1B产品的单一 B 级功能产品修订版改变了其基本尺寸和性能规格，使其从原始状态。

DS200CDBAG1B 特征

高可靠性设计，确保在恶劣的工作环境下稳定运行

支持多种类型的接触器，适应不同的控制需求

具有接触器驱动、动作监测和保护等功能

可与其他电路板和控制器集成，实现自动化控制

specification

Product ID: DS200CDBAG1A

Manufacturer: General Electric

Series: Drive control

Function description: contactor drive board

Fuse: 4 amp 125V

Test point: 3

Each of the three test points listed in the DS200CDBAG1B printed circuit board assembly is named by a combination of its factory-printed naming label, test point number, and specific intended functionality of the DS200CDBAG1B board and its larger Mark V turbine control system family of automatic drive components. The DS200CDBAG1B board is part of the second group of CDBA models. The G1B version provides coordination contactor operation, JP2 is used for coordination, and LED1 provides status information when the board selects coordination mode. The position of JP2 must be able to control the 1TB-9 and 1TB-10 inputs so that they can operate the contactors simultaneously.

When JP2 is set correctly, it allows the solid-state switch to be enabled; The switch will also turn on the 1TB-1 and 1TB-1 inputs and power on the 1TB-9 and 1TB-10 inputs so that they can continue to power the contactors. All the above information is from the GEI-100182B contactor drive board instruction manual. The GEI-100182B manual contains information on DS200CDBAG1B board potentiometers, configurable jumpers, troubleshooting, installation, and more. Before making any final purchase decision on this DS200CDBAG1B product, it is most important to understand that the single Class B functional product revision of this DS200CDBAG1B product changes its basic size and performance specifications from its original state.

DS200CDBAG1B features

High reliability design ensures stable operation in harsh working environments

Support a variety of contactors to adapt to different control needs

It has the functions of contactor drive, action monitoring and protection

It can be integrated with other boards and controllers for automatic control
