IS200ISBBG1AAB | 总线旁路板 | 燃气工业涡轮机控制管理系统

产品类型 ：Insync 总线旁路卡

制造者： GE工业系统

产品系列 ：Mark VI 涡轮机控制

产品描述

IS200ISBBG1AAB是Mark VI Insync总线旁路板。MkVI是一种蒸汽/燃气工业涡轮机控制管理系统，是通用电气Speedtronic系列控制系统的一部分。自 1960 年代后期以来，Speedtronic 控制系统一直由 GE 分销。

该IS200ISBBG1AAB在Mark VI中用作InSync总线旁路卡。它是一块小板，通常安装在DIN导轨上。这些导轨使用插入电路板角落的工厂制造孔中的螺钉安装到电路板上。IS200ISBBG1AAB上的一些工厂钻孔用导电材料环绕，包括 E1 到 E4。

该IS200ISBBG1AAB有四个板外连接器，用于与位于其他板上的组件进行通信。这包括一个端子排 （P4） 和三个插头连接器（P1 到 P3）。P1 标记为全双工，P2 标记为 XMIT 数据输出，P3 标记为 RCV 数据输入。端子条标有 24 VDC 输入。端子排有两个螺钉连接。

Product type: Insync bus bypass card

Manufacturer: GE Industrial Systems

Product Line: Mark VI turbine control

Product description

IS200ISBBG1AAB is the Mark VI Insync bus bypass board. MkVI is a steam/gas industrial turbine control management system that is part of the General Electric Speedtronic family of control systems. Speedtronic control systems have been distributed by GE since the late 1960s.

The IS200ISBBG1AAB is used as the InSync bus bypass card in Mark VI. It is a small board, usually mounted on a DIN rail. These rails are mounted to the board using screws in factory-made holes inserted into the corners of the board. Some of the factory boreholes on the IS200ISBBG1AAB are surrounded with conductive materials, including E1 to E4.

The IS200ISBBG1AAB has four off-board connectors for communication with components located on other boards. This includes a terminal block (P4) and three plug connectors (P1 to P3). P1 is labeled as full duplex, P2 is labeled as XMIT data output, and P3 is labeled as RCV data input. The terminal bar is marked with 24 VDC input. The terminal block is connected with two screws.
