IS200HFPAG2ADC  |  风扇电源板  用于为与高压隔离的电路供电

型号：IS200HFPAG2ADC

板类型： 风扇电源板

主板版本： G2系列

励磁器电压测量： 1000 VRMS格式

助焊剂/空芯线圈连接器： 结核病4

输入 电力电位变压器 ：（PPT）

相电压互感器 ：4

产品描述

IS200HFPAG2ADC是GE为适应Mark VI系统而创建的PCB组件。MKVI是GE在Speedtronic燃气轮机和蒸汽轮机管理系列中发布的最后一批系统之一。Mark VI有一个中央控制模块，通过终端板连接到系统的其余部分。

该IS200HFPAG2ADC用作高频交流/风扇电源板。由于这是一个多用途板，它可以安装在驱动系统不同位置的不同机柜内。电路板通常安装在板架或风扇外壳附近。该板接收交流或直流输入电压，然后将其转换为输出电压，例如方波或方波，用于为与高压隔离的电路供电。该板通过四个卡扣式连接器接收电压输入。电压的输出是通过八个插头连接器。

该IS200HFPAG2ADC内置四个保险丝，以保护电路板电路。它还具有单个 MOV 或金属氧化物压敏电阻，也可以保护电路。该板具有两个散热器、两个变压器、两个 LED（发光二极管）晶体管和三个高压电容器。该板使用其他材料（聚酯、乙烯基、陶瓷）的电容器。电阻器通常由金属膜材料制成。

Model: IS200HFPAG2ADC

Board type: Fan power board

Mainboard version: G2 series

Exciter voltage measurement: 1000 VRMS format

Flux/hollow coil connectors: TB 4

Input power potential transformer: (PPT)

Phase voltage transformer: 4

Product description

The IS200HFPAG2ADC is a PCB component created by GE to accommodate the Mark VI system. The MKVI is one of the last systems to be released by GE in the Speedtronic gas turbine and steam turbine management series. The Mark VI has a central control module that is connected to the rest of the system via a terminal board.

The IS200HFPAG2ADC is used as a high frequency AC/fan power supply board. Since this is a multi-purpose board, it can be installed in different cabinets in different locations of the drive system. The circuit board is usually mounted near the board frame or fan housing. The board receives an AC or DC input voltage and then converts it into an output voltage, such as a square wave or square wave, which is used to power a circuit isolated from high voltage. The board receives voltage input through four snap connectors. The voltage output is via eight plug connectors.

The IS200HFPAG2ADC has four built-in fuses to protect the board circuit. It also has a single MOV or metal oxide varistor that can also protect the circuit. The board has two radiators, two transformers, two LED (light-emitting diode) transistors, and three high-voltage capacitors. The board uses capacitors of other materials (polyester, vinyl, ceramic). Resistors are usually made of metal film materials.
