GE DS200DCFBG1BKC 直流电源板

通用电气DS200DCFBG1BKC是一款Mark V系列电源板。当安装在驱动器中时，该板为机柜风扇以及系统的控制级电源供电。在GE的驱动器系统中，该板与DC2000，AC2000，FC2000，CB2000和ME2000系列驱动器兼容。该板的标称额定源输入可以安全地测量 38 至 115VAC。该卡产生的输出频率可以测量 0 到 500 kHz 之间的任何频率，具体取决于输入电压。DS200DCFBG1BKC上有五个独立的电路。其中包括控制电平电源电路、驱动器电路、电机磁场电源电路以及交流和直流监控电路。驱动器上保险丝的诊断信息通过两个 LED 指示灯和一个霓虹灯指示灯呈现给用户。电路板中集成了三个保护保险丝，可保护电流免受中断。使用卡上的五个测试点之一时，检查电路板中的电压电平很简单。为用户提供了许多可配置的设置，以适应工作的特定需求。板上的 200 个跳线和 1 个 DIP 开关可根据用户要求进行配置。主板和驱动器包含通用电气概述的应遵循的安装参数。

The General Electric DS200DCFBG1BKC is a Mark V series power board. When installed in the drive, this board powers the cabinet fans and the control level power supply of the system. In GE's drive system, this board is compatible with DC2000, AC2000, FC2000, CB2000, and ME2000 series drives. The nominal rated source input of this board can safely measure 38 to 115VAC. The output frequency generated by this card can be measured at any frequency between 0 and 500 kHz, depending on the input voltage. There are five independent circuits on the DS200DCFBG1BKC. This includes control level power supply circuits, driver circuits, motor field power supply circuits, and AC and DC monitoring circuits. The diagnostic information of the fuse on the driver is presented to the user through two LED indicators and a neon indicator. Three protective fuses are integrated into the circuit board to protect the current from interruption. It is easy to check the voltage level in the circuit board using one of the five test points on the card. Provides users with many configurable settings to meet the specific needs of their work. The 200 jumpers and 1 DIP switch on the board can be configured according to user requirements. The motherboard and driver contain the installation parameters that General Electric should follow.
