AT686W-1-1-1-1  继电器模块  可以实现电路的通断控制

AT686W-1-1-1-1  继电器模块是一种电控制器件，当输入量的变化达到规定要求时，在电气输出电路中使被控量发生预定的阶跃变化。继电器模块通常包含多个继电器，这些继电器可以合并在一起，通过控制信号来切换电路的通断状态。每个继电器都拥有一个动触点和两个静触点。在没有任何输入信号的情况下，常闭端（NC）与公共端（COM）相连通，常开端（NO）则处于断开状态。当输入信号作用于继电器时，动触点会与常开端（NO）相连通，而与常闭端（NC）断开，从而实现电路的切换。

AT686W-1-1-1-1 继电器模块广泛应用于自动化控制电路中，起到自动调节、安全保护、转换电路等作用。常见的继电器模块有4路继电器模块和1路继电器模块等。这些模块具有不同的特点和应用场景，可以根据具体需求选择合适的模块来使用。

在使用继电器模块时，需要注意模块的引脚定义和连接方式。一般来说，继电器模块具有电源正极（VCC）、电源负极（GND）和通断信号输入引脚（IN）。在实际应用中，需要将公共端（COM）接入火线中，然后将常开端（NO）和常闭端（NC）分别接入相应的电路中。通过控制输入引脚的电平状态，可以实现电路的通断控制。

总之，AT686W-1-1-1-1 继电器模块是一种重要的电控制器件，具有广泛的应用前景和市场需求。在使用时需要注意引脚定义和连接方式，并根据具体需求选择合适的模块来使用。

The AT686W-1-1-1 relay module is an electrical control device. When the change of the input quantity meets the specified requirements, the controlled quantity will undergo a predetermined step change in the electrical output circuit. Relay modules usually contain multiple relays that can be combined to switch the on-off state of a circuit by means of a control signal. Each relay has one moving contact and two static contacts. In the absence of any input signal, the normally closed end (NC) is connected to the common end (COM), and the normally open end (NO) is disconnected. When the input signal acts on the relay, the moving contact is connected to the normally open end (NO) and disconnected from the normally closed end (NC), thus achieving circuit switching.

AT686W-1-1-1 relay module is widely used in automatic control circuit, playing the role of automatic regulation, safety protection, conversion circuit and so on. Common relay modules include 4-way relay module and 1-way relay module. These modules have different characteristics and application scenarios, you can choose the right module to use according to specific needs.

When using the relay module, it is necessary to pay attention to the pin definition and connection mode of the module. IN general, a relay module has a positive power supply (VCC), a negative power supply (GND), and an on-off signal input pin (IN). In practical applications, the common end (COM) needs to be connected to the fireline, and then the normally open end (NO) and the normally closed end (NC) are connected to the corresponding circuit respectively. By controlling the level state of the input pin, the on-off control of the circuit can be realized.

In short, the AT686W-1-1-1 relay module is an important electrical control device, which has a wide application prospect and market demand. In use, it is necessary to pay attention to the pin definition and connection mode, and select the appropriate module to use according to the specific needs.
