IS420PUAAH1A 通用输入/输出模块  有16个单工模拟通道

产品类型：通用输入输出包

部件号：IS420PUAAH1A

工作温度-40至+158°F

ControlST软件套件版本v07.02.00 c及以上

IS420PUAAH1A是通用电气的通用输入/输出模块。它被设计用于分布式控制系统和BOP(功率平衡)控制系统。通常，它在Mark VIe控制系统中使用，类似于Mark VIe系统中使用的YUAA板。这些系统是GE公司最新发布的用于管理燃气轮机和蒸汽轮机系统的最先进的Speedtronic系统。

IS420PUAAH1A设计用于ControlST版本7.02.00C或更高版本。

IS420PUAAH1A允许用户使用更少的面板，并且通过提供可以独立布线的黑色部分，为他们的系统提供更小的占地面积，从而允许逐个通道调试。该模块有16个单工模拟通道。这些可以单独配置如下:

热电偶的I / O

RTD I / O

电压输入

4- 20ma电流输入

0- 20ma电流输出

脉冲累加器

数字输入

IS420PUAAH1A 通用输入/输出模块  有16个单工模拟通道

Product type: Generic input/output package

Part number: IS420PUAAH1A

Operating temperature -40 to +158°F

ControlST Software suite version v07.02.00c or later

The IS420PUAAH1A is a general purpose input/output module from General Electric. It is designed for distributed control systems and BOP(Power balance) control systems. Typically, it is used in the Mark VIe control system, similar to the YUAA board used in the Mark VIe system. These systems are GE's latest state-of-the-art Speedtronic systems for managing gas and steam turbine systems.

The IS420PUAAH1A is designed for ControlST version 7.02.00C or later.

The IS420PUAAH1A allows users to use fewer panels and gives their systems a smaller footprint by providing black sections that can be wired independently, allowing for channel-by-channel debugging. The module has 16 simplex analog channels. These can be configured individually as follows:

I/O of a thermocouple

RTD I / O

Voltage input

4-20 mA current input

0-20 mA current output

Pulse accumulator

Digital input
