IC200MDL240B  离散输入模块  具有正逻辑或源型

产品描述.

型号：IC200MDL240B

这些离散输入模块具有正逻辑或源型

输入;它们从交流输入设备接收电流并将电流返回到公共电源。输入设备之间是连接输入的

端子和常用端子。

分立输入模块IC20OMDL140,IC200MDL141,BXIOIA8120和bxioia8240提供一组8个分立输入。

分立输入模块IC200MDL240、IC200MDL241(如下所示)和BXIOIA16120提供两组8个分立输入。

模块特点

点

Ic200MDL140、IC200MDL141、BXIOIA120、bxioia240:8路输入(1组8路)

IC200MDL240、IC200MDL241 BXIOIA16120:

16个输入(2组，每组8个)

模块ID

bxioia8 ": ffff8804ic200mdl24 "， bxioia16120: 88048804

lsolation:

用户输入逻辑(光学和帧地)250vac连续;1500VAC持续1分钟

组对组:

8分:不适用

16点:250vAC连续;

150OVAC 1分钟点对点:无

领导的指标

每个点一个LED显示单个点onoff状态ok LED表示背板电源存在

底板当前

IC200MDL14"，BXIOIA8:最大55mA

消费(sv

IC20OMDL24 , BXIOIA16120:110mA最大值

输出)

外部电源

没有一个

热降额

IC200MDL240B  离散输入模块  具有正逻辑或源型

IC200MDL14”,BXIOIA8

IC200MDL24"，BXIOAI16120

Product description.

Model: IC200MDL240B

These discrete input modules have positive logic or source type

Input; They receive current from the AC input device and return the current to the common power supply. Input devices are connected to each other

Terminals and common terminals.

Discrete input module IC20OMDL140 IC200MDL141, BXIOIA8120 and bxioia8240 provides a set of eight discrete input.

Discrete input modules IC200MDL240, IC200MDL241(as shown below), and BXIOIA16120 provide two groups of eight discrete inputs.

Module characteristics

point

Ic200MDL140, IC200MDL141, BXIOIA120, bxioia240:8 inputs (1 group of 8 inputs)

IC200MDL240, IC200MDL241 BXIOIA16120:

16 inputs (2 sets of 8 each)

Module ID

bxioia8 ": ffff8804ic200mdl24 ", bxioia16120:88048804

lsolation:

User input logic (optical and frame ground)250vac continuous; 1500VAC lasts 1 minute

Group to group:

8 marks: Not applicable

16 points :250vAC continuous;

150OVAC 1 minute Point-to-point: None

Indicators of leadership

One LED per point indicates the onoff status of a single point. ok LED indicates that the backplane power supply is present

Backplane current

IC200MDL14", BXIOIA8: Max. 55mA

Consumption (sv)

IC20OMDL24, BXIOIA16120:110mA Maximum value

Damage output)

External power supply

Not one

Heat derating

IC200MDL14 ",BXIOIA8 *: No

IC200MDL24", BXIOAI16120: See next page
