1C31129G03 模拟量输出模块

如果高速模拟输入模块使用电流输入1C31129G03或1C31116G03)个性模块，可获得所需的电压源从内部辅助电源(背板)。如果使用Pmod 1C31227G01或1C1116G02,则使用。请注意，1C31129G03同时提供现场和本地电源。

1C31129G03通道数8输入范围4- 20 mA，+1mA .+1V，+5V, +10V+20mV，50mV， +100V, +250mV分辨率14位(包括极性)保证精度(@25°C)

满量程值的+0.10%+1/2LSB @99.7%信任度。

温度系数0至24°C范围内满量程值的+0.60%。

输入阻抗: 3.3 MQ (G02， G04) 200 MQ (Go3) 菲菲尔德300

MQ @20 mA于G01菲菲尔德采样率(每秒) 16 (50 Hz)20当为60Hz时由Ovation控制器按需进行自我校准。

诊断内部模块运行故障。超出范围检测。电流输入的开环检测。

If the high-speed analog input module uses a current input 1C31129G03 or 1C31116G03 personality module, the required voltage source can be obtained from the internal auxiliary power supply (backplane). If using Pmod 1C31227G01 or 1C1116G02, use. Please note that 1C31129G03 provides both on-site and local power supplies.

1C31129G03 channel number 8 input range 4-20 mA,+1 mA+ 1V,+5V,+10V+20mV, 50mV,+100V,+250mV Resolution of 14 bits (including polarity) to ensure accuracy (@ 25 ° C)

+0.10% of full scale value+1/2LSB @ 99.7% confidence level.

+0.60% of the full scale value within the temperature coefficient range of 0 to 24 ° C.

Input impedance: 3.3 MQ (G02, G04) 200 MQ (Go3) Feifeld 300

MQ @ 20 mA is self calibrated by the Ovation controller as needed at G01 Fieldfield sampling rate (per second) of 16 (50 Hz) and 20 at 60Hz.

Diagnose internal module operation faults. Out of range detection. Open loop detection of current input.
