9200-06-02-10-00 BENTLY 双线传感器 有无源传感器间的转换

制造商:本特利内华达

产品编号:9200-06-02-10-00

产品类型:双线传感器

分类: Bently Nevada/本特利/卡件·

9200-06-02-10-00趋近式探头传感器

小靶面尺寸:直径15.2mm(0.6inch)（平面靶面》

轴直径:

小:

50.8mm (2in)

推荐小:76.2mm (3in)

机械特性

探头端部材料:聚苯撑硫（PPS)

探头壳体材料:AISI 304不锈钢（SST)

探头电缆规格:

标准电缆:75Q三维轴向FEP绝缘探头电缆，具有以下探头总长度选择:0.5，1，1.5,

2，5或9米。

大温度范围电缆:75Q三维轴向PFA绝缘探头电缆，具有以下探头总长度选择:0.5，1，1.5，2，5或9米。延伸电缆材料:75Q三维轴向FEP绝缘。

9200-06-02-10-00技术规格

9200和74712振动速度传感器如无另外说明，技术规格在+22°C(+72°F)和25 mm/s (1 in/s)在10OH时测定。

电气特性

灵敏度:当正确地终止并定位在校准角时，在10OHz(6,000 cpm)时为20mV/mm/s (500mV/in/s)土5%，在10OHz(6,000cpm)时为25mm/s(1 in/s)零到峰值土5%

频率响应:从较小工作频率(参见订货信息)到1kHz(60,000 cpm);典型值从+0到+3dB

抗冲击:承受50g峰值加速度

横向灵敏度:±10%

引线长度:在振动和3300监测器之间较长305m(1,000英尺)。长度增加时的频率衰减.

环境限制

使用和存储温度:

9200: -29°C到+21°C(-20°F到+250°F)74712:-29C到+204C(-20°F到+400°F)

环境:防灰尘和潮湿.注:关于传感器在辐射环境中的使用，

相对湿度:95%非冷凝。当订购整体电缆时不浸水

9200-06-02-10-00探头传感器是指将感受到的非电量转换成电信号输出的器件，按转换原理可以分为有源传感器和无源传感器。

有源传感器是将输入的非电量转换成电能量输出的传感器，如压电传感器、热电偶、光电池和霍尔传感器等。无源传感器是将被测量的非电量转换成电阻、电容、电感等无源元件的参量，再通过适当变换电路把这些参量转换为电压或电流输出，如电阻应变式、电容式、电感式和振弦式传感器等。

9200-06-02-10-00 BENTLY 双线传感器 有无源传感器间的转换

Manufacturer: Bentley, Nevada

Product Number :9200-06-02-10-00 Product Type: Two-wire sensor

Category: Bently Nevada/ Bentley/Card pieces ·

9200-06-02-10-00 Approach probe sensor

Small target size: Diameter 15.2mm(0.6inch) (Flat target surface)

Shaft diameter:

Small:

50.8mm (2in)

Recommended size :76.2mm (3in)

Mechanical characteristic

Probe end material: Polyphenylene sulfide (PPS)

Probe housing material :AISI 304 stainless steel (SST)

Probe cable specifications:

Standard cable :75Q 3D axial FEP insulated probe cable with the following total probe length options :0.5, 1,1.5,

2,5 or 9 meters.

Large temperature range cable :75Q 3D axial PFA insulated probe cable with the following total probe length options :0.5, 1,1.5, 2,5 or 9 meters. Extension cable material :75Q three-dimensional axial FEP insulation.

9200-06-02-10-00 Technical specifications

The 9200 and 74712 vibration velocity sensors are measured at +22°C(+72°F) and 25 mm/s (1 in/s) at 10OH unless otherwise stated.

Electrical characteristic

Sensitivity: 5% soil at 20mV/mm/s (500mV/in/s) at 10OHz(6,000cpm) and 5% soil at 25mm/s(1 in/s) zero to peak at 10OHz(6,000cpm) when properly terminated and positioned at the calibration Angle

Frequency response: from smaller operating frequencies (see ordering information) to 1kHz(60,000 cpm); Typical values range from +0 to +3dB

Shock resistance: 50g peak acceleration

Lateral sensitivity :±10%

Lead length: Longer 305m(1,000 ft) between the vibration and 3300 monitor. Frequency attenuation as length increases.

Environmental restriction

Use and storage temperature:

: 9200-29 ° C to + 21 ° C (20 ° F to + 250 ° F) : 74712-29 - C to + 204 C (20 ° F to 400 ° F) +

Environment: Dust and moisture proof. Note: Regarding the use of sensors in radiation environments,

Relative humidity :95% non-condensing. Do not soak when ordering integral cables

9200-06-02-10-00 probe sensor refers to the device that converts the felt non-electricity into an electrical signal output, which can be divided into active sensors and passive sensors according to the conversion principle.

Active sensors are sensors that convert the input non-electricity into electrical energy output, such as piezoelectric sensors, thermocouples, photocells and Hall sensors. Passive sensor is to be measured non-electricity into resistance, capacitance, inductance and other passive components of the parameters, and then through the appropriate conversion circuit to convert these parameters into voltage or current output, such as resistance strain gauge, capacitance, inductance and vibrating wire sensors.
