125800-01是Bently Nevada公司开发的Keyphasorl/0模块它是3500/25增强型Keyphasor模块的一部分3500框架中的监视器模块接收来自半高的Keyphasor信号，这是一个双通道模块，称为Keyphasor模块，当轴上的Keyphasor标i记与Keyphasor传感器对齐时，模块使用磁性拾音据或接近探头检测对齐情况，并将输入信号转换为数字Kevphasor信号。对于常规设置，3500机城保护系统最多接受四人Kevphasor信号，对于成对配置，最多可接受八个

125800-01功能描述

由转抽或齿轮每转一次或每转几次产生的关键相量信号可用于精确识别正时。因此，3500监控模块和外部诊断工具可以测量抽转速和矢量特性，如

1X振幅和相位增强型Keyphasor模块是增强型3500系统模块，它改进了以前设计的Keyphasor信号处理能力，同时在形状、配合和功能方面保持与当前

Kevphasor模块的完全向下兼容性，以用于日系统。Keyphasor模块PWA 125792-01已被更新的149369-01模块完全取代。当三模几余TMR)用需要系统Keyphasor输时，3500系统应使用两在这种设计中，这些模块同时向机架中的其他模块传送主要和次要Kevphasor信号

Keyphasor模块。

BENTLY 125800-01 传感器

The 125800-01 is a Keyphasorl/0 module developed by Bently Nevada. It is part of the 3500/25 enhanced Keyphasor module. The monitor module in the 3500 frame receives the Keyphasor signal from half height, which is a dual channel module. Called the Keyphasor module, when the Keyphasor marker on the shaft is aligned with the Keyphasor sensor, the module detects the alignment using a magnetic pickup or proximity probe and converts the input signal into a digital Kevphasor signal. The 3500 City protection system accepts up to four person Kevphasor signals for a regular setup and up to eight for a paired configuration

125800-01 Function Description

The critical phasor signal generated by the rotor or gear each turn or several turns can be used to accurately identify the timing. Therefore, the 3500 monitoring module and external diagnostic tools can measure the pumping speed and vector characteristics, such as

The 1X Amplitude and Phase Enhanced Keyphasor module is an Enhanced 3500 system module that improves the previously designed Keyphasor signal processing capabilities while remaining current in terms of shape, fit, and functionality

Full backward compatibility of the Kevphasor module for use with daily systems. The Keyphasor module PWA 125792-01 has been completely replaced by the newer module 149369-01. When a three-mode multi-mode TMR requires system Keyphasor output, the 3500 system should use two. In this design, these modules transmit both primary and secondary Kevphasor signals to other modules in the rack

Keyphasor module.
