3500/50-01-00 值被绕过或失效(例如,当传感器)。所选值可以介于最小值和最大值之间满量程范围值。只有记录器输出中可用的值,通信网关和显示器3500/50-01-00接口模块夹在中间当比例值无效时指定一个值。记录仪输出3500/50-01-00 发送到 4 至 20mA 记录仪的通道比例值。记录仪输出与通道上的测量值成正比满量程范围。比例值的增加将是在条形图显示屏上显示高档位将导致增加当前从记录器输出。如果通道被旁路,输出将是箝位至所选箝位值或 2mA(如果箝位 2mA已选择)。
3500/50-01-00100 毫秒(典型值)选项仅适用于危险时间延迟,并且具有结果如下:
-如果 100 毫秒选项已关闭 ():
-危险时间延迟可以设置为一秒间隔(从 1 到60).
-危险时间延迟可以设置为任何两个可用比率价值。
如果 100 毫秒选项已打开 ():- 危险时间延迟设置为 100 毫秒。
-危险延时只能设置为主要比例价值。
The 3500/50-01-00 value is bypassed or invalidated (for example, when a sensor). The selected value can be between the minimum and maximum full-scale range values. Only the values available in the recorder output, communication gateway and display 3500/50-01-00 interface module are sandwiched in the middle, and a value is specified when the proportional value is invalid. The recorder outputs channel proportional values from 3500/50-01-00 to 4 to 20mA recorders. The recorder output is proportional to the measured value on the channel over the full scale range. An increase in the proportional value will be the display of high gear on the bar chart display will result in an increase in the current output from the recorder. If the channel is bypassed, the output will be clamped to the selected clamping value or 2mA (if clamping 2mA is selected).
The 3500/50-01-00100 millisecond (typical value) option is only applicable to hazardous time delays and has the following results:
-If the 100 millisecond option is turned off ():
-The danger time delay can be set to a one second interval (from 1 to 60)
-Danger time delay can be set to any two available ratio values.
If the 100 millisecond option is turned on (): - Danger time delay is set to 100 milliseconds.
-Danger delay can only be set as the main proportional value.
