BENTLY 138607-01 瞬态数据接口模块

138607-01是由本特利内华达开发的瞬态数据接口模块。它属于3500系列组件。瞬态数据接口（TDI）将3500监控系统连接到GE的System 1机械管理软件。TDI 将 3500/20 RIM 的功能与通信处理器（如 TDXnet）的数据收集功能相结合。

配置钥匙锁

• 用于将 3500 机架设置为 RUN 或 PROGRAM 模式。运行模式允许正常的机架操作，但阻止配置更改。
• PROGAM 模式允许正常的机架操作以及本地或远程机架配置。
• 钥匙可以从机架的任一位置取出，允许交换机保持在运行或程序状态。将交换机锁定在 RUN 位置可防止未经授权的机架重新配置。当交换机锁定在 PROGRAM 位置时，可以随时远程重新配置机架。

前面板指示灯

• OK LED：指示 3500/22M 何时正常运行
• TX/RX LED：指示 3500/22M 何时与机架中的其他模块通信。
• TM LED：指示 3500 机架何时处于跳闸乘法模式。
• 配置正常 LED：表示 3500 机架具有有效的配置。

138607-01 is a transient data interface module developed by Bently Nevada. It belongs to the 3500 series components. The Transient Data Interface (TDI) connects the 3500 monitoring system to GE's System 1 mechanical management software. TDI combines the functionality of the 3500/20 RIM with the data collection function of communication processors such as TDXnet.

Configure keylock

Used to set the 3500 rack to RUN or Program mode. The operating mode allows normal rack operation, but prevents configuration changes.

The PROGAM mode allows for normal rack operation as well as local or remote rack configuration.

The key can be removed from any position in the rack, allowing the switch to remain in a running or program state. Locking the switch in the RUN position prevents unauthorized rack reconfiguration. When the switch is locked in the Program position, the rack can be reconfigured remotely at any time.

Front panel indicator light

OK LED: Indicates when the 3500/22M is operating normally

TX/RX LED: Indicates when the 3500/22M communicates with other modules in the rack.

TM LED: Indicates when the 3500 rack is in trip multiplication mode.

Configuration OK LED: Indicates that the 3500 rack has a valid configuration.
