2DS100.60-1 | 编码器   | ECE161-0  | ECCP70-01

型号: 2DS100.60-1

类别: 编码器

成色：全新/非全新

货期：现货

质保：一年

快递：顺丰/德邦

描述：

2010 电子鼓音序器 Absolut 编码器，SSI/并行，16 位 3 差分输入，RS422 电平，100 kHz 3 差分输出，RS422 电平，100 kHz 16 个数字输入 24 VDC，5 微秒，灌电流 单独订购接线端子 1 x TB140！

编码器模块是一种机电装置，通常用于将轴的角运动转换为A/B两相相位偏差90°的脉冲信号。这些脉冲信号可以用于测量旋转的角度、速度和方向。编码器模块广泛应用于各种控制系统，如电机控制、机器人、自动化设备、传感器网络等。

2DS100.60-1编码器模块的类型有很多，其中一种常见的类型是旋转编码器。旋转编码器通常由一个中心有轴的光电盘组成，盘上有环形通、暗的刻线。当轴旋转时，刻线会经过光电发射和接收器件，产生脉冲信号。这些脉冲信号可以通过计数器进行计数，从而确定轴旋转的角度和速度。

2DS100.60-1编码器模块的输出信号通常为脉冲信号或代码信号，可以通过后继电路进行处理。根据编码器模块的类型和应用场景，输出信号的具体形式和参数也会有所不同。

总的来说，2DS100.60-1编码器模块是一种重要的传感器设备，用于测量和控制旋转运动。它的应用广泛，对工业自动化和智能化的发展起到了重要的推动作用。

2DS100.60-1 | encoder | ECE161-0 | ECCP70-01

Model: 2DS100.60-1

Category: encoder

Finish: New/not new

Delivery time: from stock

Warranty: One year

Express: SF Express/Debon

Description:

Absolut encoder, SSI/ parallel, 16-bit 3 differential input, RS422 level, 100 kHz 3 differential output, RS422 level, 100 kHz 16 digital input 24 VDC, 5 microseconds, Order the terminal 1 x TB140 separately for filling current!

An encoder module is an electromechanical device usually used to convert the angular motion of an axis into A/B two-phase pulse signal with a phase deviation of 90°. These pulse signals can be used to measure the Angle, speed and direction of rotation. Encoder modules are widely used in various control systems, such as motor control, robotics, automation equipment, sensor networks, etc.

2DS100.60-1 There are many types of encoder modules, one of the common types is the rotary encoder. Rotary encoders usually consist of an optical disk with a central shaft, on which there are annular, dark grooves. When the shaft is rotated, the engraving passes through the phototransmitting and receiving devices, producing a pulse signal. These pulse signals can be counted by a counter to determine the Angle and speed at which the shaft is rotating.

The output signal of the 2DS100.60-1 encoder module is usually a pulse signal or a code signal, which can be processed by a successor circuit. According to the type of encoder module and application scenario, the specific form and parameters of the output signal will also be different.

Overall, the 2DS100.60-1 encoder module is an important sensor device for measuring and controlling rotary motion. It is widely used and has played an important role in promoting the development of industrial automation and intelligence.
