模拟量输入模块 AI815  将模拟信号转换为数字信号

编号：3BSE052604R1

一般信息

产品编号：编号：3BSE052604R1

ABB型号名称：AI815型

目录说明：AI815 模拟量输入 HART 8 通道

详细描述：0(4)..20毫安，0（1）..5V，12位，单端。电流限制的变送器功率分配。

使用模块端接单元 TU810、TU812、TU814、TU818、TU830、TU833、TU835、TU838。

介质描述：0(4)..20毫安，0（1）..5V，12位，单端。电流限制的变送器功率分配。

使用模块端接单元 TU810、TU812、TU814、TU818、TU830、TU833、TU835、TU838。

产品类型：I-O_Module

订购

海关编码：853890-- 适合单独或主要与品目 85.35、85.36 或 85.37 的设备一起使用的部件。

海关税则号：85389099

尺寸

产品净深度/长度：102 毫米

产品净高：119 毫米

产品净宽：45 毫米

产品净重：0.2 千克

专门的

通道类型：人工智能

输入通道数：8

输出通道数：0

环境的

RoHS状态：遵循欧盟指令 2011/65/EU

WEEE类别：5.小型设备（外部尺寸不超过50厘米）

模拟量输入是指将连续变化的物理量（如温度、压力、流量等）转换为电信号的过程。这些电信号可以是模拟信号，如电压或电流，它们的幅度与物理量的大小成比例关系。

在计算机控制系统中，模拟量输入通常用于测量和控制各种物理量。例如，在工业控制中，可以使用传感器将温度、压力、流量等物理量转换为模拟信号，然后将这些信号输入到模拟量输入模块中进行处理。

AI815模拟量输入模块通常包括模数转换器（ADC），它将模拟信号转换为数字信号，以便计算机可以处理和分析这些数据。模拟量输入模块还可以提供信号调理功能，如滤波、放大、校准等，以确保输入信号的准确性和可靠性。

AI815模拟量输入模块通常支持多种输入信号类型，如电压、电流、热电偶、热电阻等。它们还可以支持不同的输入范围和分辨率，以满足不同的应用需求。

总之，AI815模拟量输入是计算机控制系统中非常重要的一部分，它允许计算机对各种物理量进行测量和控制，从而实现更精确和高效的控制。

 模拟量输入模块 AI815  将模拟信号转换为数字信号

Number: 3BSE052604R1

General information

Product Number: Number: 3BSE052604R1

ABB model name: AI815

Directory Description: AI815 Analog input HART 8 channel

Detailed description: 0(4)... 20 mah, 0 (1)... 5V, 12-bit, single-ended. Current limited transmitter power distribution.

Use module terminating units TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838.

Media description: 0(4)... 20 mah, 0 (1)... 5V, 12-bit, single-ended. Current limited transmitter power distribution.

Use module terminating units TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838.

Product type: I-O_Module

order

Customs Code: 853890- Parts suitable for use alone or mainly with equipment of heading 85.35, 85.36 or 85.37.

Customs Code: 85389099

dimension

Product net depth/length: 102 mm

Product height: 119mm

Product width: 45 mm

Net weight: 0.2kg

technical

Channel type: Artificial Intelligence

Input channels: 8

Number of output channels: 0

environmental

RoHS status: Compliance with EU Directive 2011/65/EU

WEEE Category: 5. Small equipment (external size does not exceed 50 cm)

Analog input refers to the process of converting continuously changing physical quantities (such as temperature, pressure, flow, etc.) into electrical signals. These electrical signals can be analog signals, such as voltage or current, and their amplitude is proportional to the size of the physical quantity.

In computer control systems, analog inputs are often used to measure and control various physical quantities. For example, in industrial control, sensors can be used to convert physical quantities such as temperature, pressure, and flow into analog signals, which are then input into analog input modules for processing.

The AI815 analog input module typically includes an analog-to-digital converter (ADC), which converts the analog signal into a digital signal so that the computer can process and analyze the data. The analog input module can also provide signal conditioning functions, such as filtering, amplification, calibration, etc., to ensure the accuracy and reliability of the input signal.

The AI815 analog input module typically supports a variety of input signal types, such as voltage, current, thermocouple, thermal resistance, etc. They can also support different input ranges and resolutions to meet different application needs.

In short, the AI815 analog input is a very important part of the computer control system, which allows the computer to measure and control various physical quantities, so as to achieve more accurate and efficient control.
