531X305NTBANG1 终端板

安装此NTB/3TB终端板时，它为驱动器提供了一系列功能。安装时，531X305NTBANG1能够产生稳压和非稳压电源。稳压电源速率为 5 VDC 和 15 VDC，而非稳压电源的额定电压为 24 VDC 或 125 VAC。额定电压为 5 V 和 15 V 的编码器可以使用板载跳线进行配置。该板还包括七个继电器输出，由 A 型或 C 型输出组成。每个继电器内的触点的额定值为 120 VAC。低电平模拟I/O也可以使用板上的四个电位计进行缩放。

531X305NTBANG1 NTB/3TB 终端板包含许多安装参数。在开始设备安装之前查看这些指南将有助于降低电路板损坏的风险。从 AX Control 发货时，此卡将包裹在保护性静电减少塑料袋中。安装开始后，请参阅器件手册和数据表，了解电路板接线的完整指南。此端子板的技术支持最初由设备制造商通用电气提供。

When installing this NTB/3TB terminal board, it provides a series of functions for the drive. During installation, 531X305NTBANG1 can generate regulated and non regulated power supplies. The regulated power supply has a speed of 5 VDC and 15 VDC, while the rated voltage of non regulated power supply is 24 VDC or 125 VAC. Encoders with rated voltages of 5 V and 15 V can be configured using onboard jumpers. The board also includes seven relay outputs, consisting of A-type or C-type outputs. The rated value of the contacts inside each relay is 120 VAC. Low level analog I/O can also be scaled using the four potentiometers on the board.

The 531X305NTBANG1 NTB/3TB terminal board contains many installation parameters. Reviewing these guidelines before starting device installation will help reduce the risk of circuit board damage. When shipped from AX Control, this card will be wrapped in a protective static electricity reducing plastic bag. After installation begins, please refer to the device manual and data sheet for complete guidance on circuit board wiring. The technical support for this terminal board was initially provided by device manufacturer General Electric.
