编号:3AFE64610805

—般信息

产品编号:

编号:3AFE64610805

RTAC-01 ABB  脉冲编码器接口 建立仪器虚拟板面

ABB型号名称:脉冲编码器-INT RTAC-O1

目录说明:

脉冲编码器-INT RTAC-O1;脉冲编码器接口RTAC-O1 ( 15V和24v )

类别

零部件工传动》服务”备件和耗材”零件

使用地点(作为“产品”的备件)

订购

原产国:

德国(DE)芬兰(FI)

海关税则号:85371098

发票说明:脉冲编码器接口RTAC-o1 ( 15V和24v )

按订单生产:不

最小起订量:1件

仅引用:不

销售计量单位:块

尺寸产品净重:0.2干克

产品净深度/长度:165毫米

产品净高:50毫米

产品净宽:115毫米

专门的

框架尺寸:一个

其他信息

中文名称:选项

环境的

wEEE类别:产品不在WEEE范围内

RTAC-01是ABB集团生产的一款主控板，它利用计算机界面和在线帮助功能，建立仪器虚拟板面，通过计算操作完成对对象的测试分析功能。

RTAC-01虚拟仪器实质上是"软硬结合""虚实结合"的产物。它充分利用计算机技术来实现和扩展传统仪器的功能。在虚拟仪器中，硬件只是信号传输的介质，软件才是整个仪器系统的关键。

RTAC-01 ABB 脉冲编码器是一种光学式位置检测元件，编码盘直接装在电机的旋转轴上，以测出轴的旋转角度位置和速度变化，其输出信号为电脉冲。

RTAC-01 ABB 脉冲编码器的工作原理是当圆光栅与工作轴一起转动时，光线透过两个光栅的线纹部分，形成明暗相间的条纹。光电元件接受这些明暗相间的光信号，并转换为交替变换的电信号。该电信号为两组近似于正弦波的电流信号A和B，A和B信号相位相差90°，经放大和整形变成方形波。通过两个光栅的信号，还有一个“每转脉冲”，称为Z相脉冲，该脉冲也是通过上述处理得来的。Z脉冲用来产生机床的基准点。后来的脉冲被送到计数器，根据脉冲的数目和频率可测出工作轴的转角及转速。其分辨率取决于圆光栅的圈数和测量线路的细分倍数。

RTAC-01 ABB  脉冲编码器接口 建立仪器虚拟板面

Number :3AFE64610805

- General Information

Product Number:

Number :3AFE64610805

ABB Model name: Pulse encoder -INT RTAC-O1

Directory description:

Pulse encoder -INT RTAC-O1; Pulse encoder interface RTAC-O1 (15V and 24v)

category

Parts Man Drive Service "Spare parts and consumables" parts

Place of use (as spare parts for the "Product")

order

Country of origin:

Germany (DE) Finland (FI)

Customs tariff Code :85371098

Invoice description: Pulse encoder interface RTAC-o1 (15V and 24v)

Build-to-order: No

Minimum order quantity :1 piece

Quote only: No

Sales unit: block

Size Net weight :0.2 dry grams

Product net depth/length :165 mm

Product height :50 mm

Product width :115 mm

technical

Frame size: one

Other information

Chinese name: Option

environmental

wEEE Category: The product is not included in the WEEE

RTAC-01 is a master control board produced by ABB Group. It uses the computer interface and online help function to establish the instrument virtual board surface and complete the test and analysis function of the object through calculation operation.

RTAC-01 virtual instrument is essentially the product of "soft and hard combination" and "virtual and real combination". It makes full use of computer technology to realize and extend the functions of traditional instruments. In virtual instrument, the hardware is only the medium of signal transmission, and the software is the key of the whole instrument system.

RTAC-01 ABB pulse encoder is an optical position detection element, the coding disc is directly installed on the rotating shaft of the motor to measure the rotation Angle position and speed change of the shaft, and its output signal is an electrical pulse.

The RTAC-01 ABB pulse encoder works on the principle that when the circular grating is rotated with the working axis, the light passes through the linear part of the two grating, forming a stripe between light and dark. The photoelectric element receives these light signals alternating between light and dark, and converts them into alternating electrical signals. The electric signal consists of two sets of current signals A and B, which are similar to sine waves. The phase difference of A and B signals is 90°, and they are amplified and shaped into square waves. The signal through the two gratings, there is also a "per revolution pulse", called the Z-phase pulse, which is also obtained by the above processing. The Z pulse is used to generate the reference point of the machine tool. The subsequent pulses are sent to the counter, and the rotation Angle and speed of the working shaft can be measured according to the number and frequency of the pulses. Its resolution depends on the number of turns of the circular grating and the subdivision multiple of the measurement line.
