REF620  ABB  工业配电系统

型号：REF620

品牌：ABB

REF620 作为专用馈线保护装置,专门用于保护、控制、测量和监视公共和工业配电系统

REF620 IEC馈线保护和测控装置,作为专用馈线保护装置，专门用于保护、控制、测量和监视公共和工业电网，包括辐射﹐环形和网状电网。REF620提供馈线过流和接地故障保护﹐该保护可应用于中性点不接地网络和电阻或阻抗中性点接地网络。此外,利用装置先进的站级间通信功能，REF620也可以用于环形网状配电网络或辐射网络保护。

REF620IEC馈线保护和测控装置有单母线和双母线两种配置可选,每种母线配置又有一个或两个断路器及多个开关装置配置可选。装置支持大量手动和电动隔离开关和接地开关。可用I/o 的数量可根据ABB的 RIO600远方l/o装置的需要而增加。

REF620 IEC馈线保护和测控装置以支持变电站IEC61850通信标准为特点﹐涵盖垂直和水平通信，包含带开关量信号和模拟量信号的GOOSE报文以及基于IEC 61850-8-1的定值整定。REF620还支持DNP3,IEC 60870-5-103和Modbus规约。REF62o通过PRP或HSR规约在通信故障时为无延时的冗余以太网提供一个可选以太网口或提供一个环网自愈RSTP通信。该解决方案消除了单点故障影响﹐提高了通信可靠性。该解决方案可以应用到基于以太网的IEC 61850,Modbuso和DNP3规约。

REF620是ABB Relion@产品家族中的620保护测控装置产品系列的成员。

主要优势

·集成在一台继电保护装置中的保护、控制、监测和管理为公共和工业配电系统提供了紧凑和通

用的方案

·具有广泛的保护和控制功能,可以用传感器或传统的CT、PT

·功能的可扩展性和广泛的应用性﹐使用户可轻松定制配置应用程序以满足具体要求·快速安装和测试的可插拔式设计

·带单线图显示的大液晶屏,可通过本地或易于连接和浏览的HMI来访问·周到的产品全寿命周期服务

主要特性

·广泛的保护和测控功能可应用于进线或出线·具有高灵敏度和选择性的多频导纳接地保护组合·具有先进、快速的短路、接地故障定位功能

·几种可选的功能包—适用于分布式发电、电容器、基本的电机和弧光保护

·支持IEC6185o第一版和第二版﹐包括冗余HSR和PRP,GOOSE和IEC61850-9-2

·支持 Modbus、DNP3 , IEC 60870-5-103通信协议和不同时间同步的方法，包括IEEE1588 v2的精密时间协议。

REF620  ABB  工业配电系统

Model: REF620

Brand: ABB

The REF620 is a dedicated feeder protection device designed to protect, control, measure and monitor public and industrial power distribution systems

The REF620 IEC Feeder Protection and Measurement and control device is a dedicated feeder protection device specifically designed to protect, control, measure and monitor public and industrial power grids, including radiant, ring and mesh power grids. The REF620 provides feeder overcurrent and ground fault protection, which can be applied to neutral ungrounded networks and resistance or impedance neutral ground networks. In addition, the REF620 can also be used for ring mesh distribution networks or radiation network protection, using the device's advanced interstation communication capabilities.

The REF620IEC feeder protection and measurement and control devices are available in single and dual bus configurations, each bus configuration with one or two circuit breakers and multiple switching device configurations. The device supports a large number of manual and electric isolation switches and ground switches. The amount of available I/o can be increased according to the needs of ABB's RIO600 remote l/o devices.

The REF620 IEC feeder protection and measurement and control unit features support for the substation IEC61850 communication standard, covering vertical and horizontal communication, GOOSE messages with switching and analog signals, and set setting based on IEC 61850-8-1. The REF620 also supports DNP3,IEC 60870-5-103, and Modbus protocols. REF62o provides an optional Ethernet interface for redundant Ethernet without delay or a ring self-healing RSTP communication in the event of a communication failure via PRP or HSR protocols. This solution eliminates the single point of failure and improves communication reliability. The solution can be applied to Ethernet-based IEC 61850,Modbuso and DNP3 protocols.

The REF620 is a member of ABB's family of 620 protective measurement and control devices in the Relion@ product family.

Major advantage

Protection, control, monitoring and management integrated in a single relay protection unit provides compactness and connectivity for public and industrial distribution systems

Scheme used

A wide range of protection and control functions can be used with sensors or traditional CT, PT

· Extensibility and wide application, allowing users to easily customize and configure applications to meet specific requirements · Pluggable design for quick installation and testing

· Large LCD screen with single line chart display, accessible locally or through an HMI that is easy to connect and browse · Thoughtful product life cycle service

Main characteristics

· Extensive protection and measurement and control functions can be applied to incoming or outgoing lines · Multi-frequency admittance ground protection combination with high sensitivity and selectivity · Advanced and fast short-circuit and ground fault location functions

Several optional feature packages - suitable for distributed generation, capacitors, basic motors and arc protection

· Support IEC6185o 1st and 2nd editions, including redundant HSR and PRP,GOOSE and IEC61850-9-2

· Support Modbus, DNP3, IEC 60870-5-103 communication protocols and different time synchronization methods, including IEEE1588 v2 precision time protocol.
