为了保证系统在工业电磁环境中免受或减少内外电磁干扰，必须从设计阶段开始便采取三个方面抑制措施：抑制干扰源；切断或衰减电磁干扰的传播途径；提高装置和系统的抗干扰能力。     这三点就是抑制电磁干扰的基本原则。     控制系统的抗干扰是一个系统工程，要求制造单位设计生产出具有较强抗干扰能力的产品，且有赖于使用部门在工程设计、安装施工和运行维护中予以全面考虑，并结合具有情况进行综合设计，才能保证系统的电磁兼容性和运行可靠性。     进行具体工程的抗干扰设计时，应主要以下方面。

在选择设备时，首先要选择有较高抗干扰能力的产品，其包括了电磁兼容性(emc)，尤其是抗外部干扰能力，如采用浮空技术、隔离性能好的控制系统系统；其次还应了解生产厂给出的抗干扰指标，如共模拟制比、差模拟制比，耐压能力、允许在多大电场强度和多高频率的磁场强度环境中工作；另外是靠考查其在类似工作中的应用实绩。     在选择国外进口产品要注意：我国是采用220v高内阻电网制式，而欧美地区是110v低内阻电网。     由于我国电网内阻大，零点电位漂移大，地电位变化大；工业企业现场的电磁干扰至少要比欧美地区高4倍以上，对系统抗干扰性能要求更高，在国外能正常工作的控制系统产品在国内工业就不一定能可靠运行，这就要在采用国外产品时，按我国的标准(gb/t13926)合理选择。

控制比较复杂，控制功能要求比较高的工程项目中（如要实现ＰＩＤ运算、闭环控制、通信联网等），可视控制规模及复杂程度来选用中档或高档机。其中高档机主要用于大规模过程控制、全ＰＬＣ的分布式控制系统以及整个工厂的自动化等。
