ABB UAC389AE02 HIEE300888R0002也是一种电路板，其运用的范围虽不如电路板来的宽泛，但却比普通的电路板来的智能、自动化。简单的说，能起到控制作用的电路板，才可称为控制板。大到厂家的自动化生产设备，小到孩童用的玩具遥控汽车，内部都用到了控制板

中文名控制板外文名Control board电机控制板自动化设备最为关键部件工业控制板电源控制板分 类主控板和驱动板

【硬件规格】

◆系统

CPU：32位RISC工业级ARM9处理器，180MHz主频

DRAM：32MB

Nor Flash：8MB

Nand Flash：64MB/128MB/256MB（可选）

USB Host 2.0 A型接头

安装运行Linux2.6操作系统，支持多种文件系统

◆有线网络

1个10/100M自适应以太网口，RJ45型插槽，1.5kv电磁隔离保护

◆无线网络

GSM/GPRS蜂窝通信单元

射频波段900/1800MHz

GPRS Class12

支持SMS，支持APN接入

支持软件控制（打开/关闭）

SIM卡槽

◆串型通讯

1个RS232串口，DEBUG Console，DB9-Male，

1个RS485串口，DB9-Male，

1个RS232串口，DB9-Male，

可设置数据位、停止位、校验位、流控、波特率

◆模拟量输入

8路，全部支持软件控制（打开/关闭）

其中：

6路，量程4~20mA，电流信号，支持两线制传感器

2路，量程0~40V，电压信号

12位分辨率

接线端子，5.08mm间距，螺丝紧固式

ABB UAC389AE02 HIEE300888R0002 电路板

ABB UAC389AE02 HIEE300888R0002 is also a circuit board, although the scope of its use is not as broad as the circuit board, but it is more intelligent and automated than the ordinary circuit board. Simply put, a circuit board that can play a control role can be called a control board. Large manufacturers of automated production equipment, small children's toy remote control car, the internal use of the control board

Chinese name Control board Foreign name control board Motor control board Automation equipment the most critical component Industrial control board Power control board is divided into main control board and drive board

【 Hardware Specifications 】

◆ System

CPU: 32-bit RISC industrial-grade ARM9 processor, 180MHz main frequency

DRAM: 32MB

Nor Flash: 8MB

Nand Flash: 64MB/128MB/256MB (optional)

USB Host 2.0 Type A connector

Install and run Linux2.6 operating system and support multiple file systems

◆ Wired network

1 10/100M adaptive Ethernet port, RJ45 slot, 1.5kv electromagnetic isolation protection

◆ Wireless network

GSM/GPRS cellular communication unit

The RF band is 900/1800 MHZ

GPRS Class12

Supports SMS and APN access

Support software control (on/off)

SIM card slot

◆ String communication

1 RS232 serial port, DEBUG Console, DB9-Male,

1 RS485 serial port, DB9-Male,

1 RS232 serial port, DB9-Male,

Data bit, stop bit, check bit, flow control, baud rate can be set

◆ Analog input

8 channels, all support software control (open/closed)

Among them:

6 channels, measuring range 4~20mA, current signal, support two-wire sensor

2 channels, range 0~40V, voltage signal

12-bit resolution

Terminal, 5.08mm pitch, screw fastening type
