ABB XVC767AE102 3BHB007209R0102 运动控制器模块

ABB XVC767AE102 3BHB007209R0102   运动控制器模块

ABB XVC767AE102 3BHB007209R0102 是保护负载或控制对象以及防止操作错误或控制失败而进行连锁控制的回路。在直接控制负载的同时，安全保护回路还给PLC输入信号，以便于PLC进行保护处理。安全回路一般考虑以下几个方面。

（1）短路保护应该在PLC外部输出回路中装上熔断器，进行短路保护。最好在每个负载的回路中都装上熔断器。

（2）互锁与联锁措施除在程序中保证电路的互锁关系，PLC外部接线中还应该采取硬件的互锁措施，以确保系统安全可靠地运行。

（3）失压保护与紧急停车措施PLC外部负载的供电线路应具有失压保护措施，当临时停电再恢复供电时，不按下“启动”按钮PLC的外部负载就不能自行启动。这种接线方法的另一个作用是，当特殊情况下需要紧急停机时，按下“急停”按钮就可以切断负载电源，同时“急停”信号输入PLC。

（4）极限保护在有些如提升机类超过限位就有可能产生危险的情况下，设置极限保护，当极限保护动作时直接切断负载电源，同时将信号输入PLC。

ABB XVC767AE102 3BHB007209R0102   运动控制器模块

ABB XVC767AE102 3BHB007209R0102 is the interlocking control loop that protects the load or control object and prevents operation errors or control failures. In the direct control of the load at the same time, the safety protection loop to the PLC input signal, in order to facilitate the PLC protection processing. Safety circuits generally consider the following aspects.

(1) Short-circuit protection should be installed in the PLC external output circuit fuse, short-circuit protection. It is best to install a fuse in the circuit of each load.

(2) Interlock and interlock measures in addition to ensuring the interlock relationship of the circuit in the program, the external wiring of the PLC should also take hardware interlock measures to ensure the safe and reliable operation of the system.

(3) Voltage loss protection and emergency shutdown measures PLC external load power supply line should have voltage loss protection measures, when the temporary power failure and then restore power supply, do not press the "start" button PLC external load can not start by itself. Another function of this wiring method is that when emergency shutdown is required under special circumstances, the load power supply can be cut off by pressing the "emergency stop" button, and the "emergency stop" signal is input to the PLC.

(4) Limit protection In some cases such as elevator class exceeding the limit may produce danger, set the limit protection, when the limit protection action directly cut off the load power supply, while the signal input PLC.
