系统服务器主要负责对域内系统数据的集中管理和监视，包括报警、日志、事故追忆等事件的捕捉和记录管理，并为域内其它各站的数据请求（包括实时数据、事件信息和历史记录）提供服务和为其它域的数据请求提供服务。运行系统以系统服务器为中心，完成所有功能。系统服务器还提供二次数据处理和历史数据管理和存档功能。

现场控制站是DCS系统实现数据采集和过程控制的重要站点，主要完成数据采集、工程单位变换、控制算法处理、输出控制、通过系统网络将数据和诊断结果传送到系统服务器等功能。现场控制站由主控单元、智能I/O单元、电源单元和专用机柜四部分组成，在主控单元和智能I/O单元上，分别固化了实时控制软件和I/O单元运行软件。现场控制站内部采用了分布式的结构，与系统网络相连接的是现场控制站的主控单元，可冗余配置。主控单元通过控制网络（CNET）与各个智能I/O单元实现连接。

工业公司应确保自身网络设计良好，有着防护周全的边界。企业应按ISA IEC 62443标准划分自身网络，保护所有无线应用，部署能快速排除故障的安全远程访问解决方案。公司网络，包括其工业网络基础设施设备，都应列入监视对象范围。运营技术(OT)团队可能会觉得公司的终端受到边界防火墙、专利安防软件、专业协议和物理隔离的防护，可以抵御数字攻击。但事实不是这样的，雇员、承包商和供应链员工将他们的笔记本电脑或U盘带入企业网络时，这些安全防护措施就被绕过了。必须确保所有终端都是安全的，要防止员工将自己的设备接入公司网络。事实上，黑客可以侵入OT环境中基于PC的终端。公司企业还应保护其IT终端不受OT环境中横向移动的数字攻击侵袭。

ABB 5SHY4045L0001 3BHB018162R0001 扩展器模块

The system server is mainly responsible for the centralized management and monitoring of system data in the domain, including the capture and record management of alarms, logs, accident memories and other events, and provides services for data requests of other stations in the domain (including real-time data, event information and historical records) and for data requests of other domains. The running system takes the system server as the center and completes all functions. The system server also provides secondary data processing and historical data management and archiving functions.

The field control station is an important station for DCS system to realize data acquisition and process control, which mainly completes the functions of data acquisition, engineering unit transformation, control algorithm processing, output control, and transmitting data and diagnosis results to the system server through the system network. The field control station consists of four parts: main control unit, intelligent I/O unit, power supply unit and special cabinet. On the main control unit and intelligent I/O unit, real-time control software and I/O unit running software are solidified respectively. The field control station adopts a distributed structure, and the main control unit of the field control station is connected with the system network, which can be configured redundantly. The main control unit is connected with each intelligent I/O unit through a control network (CNET).

Industrial companies should ensure that their networks are well designed and have well-protected borders. Enterprises should divide their own networks according to ISA IEC 62443 standard, protect all wireless applications, and deploy secure remote access solutions that can quickly troubleshoot. The company network, including its industrial network infrastructure equipment, should be included in the scope of monitoring. Operational Technology (OT) teams may feel that the company's terminals are protected by border firewalls, proprietary security software, professional protocols and physical isolation, and can resist digital attacks. But this is not the case. When employees, contractors and supply chain employees bring their laptops or USB flash drives into the enterprise network, these security measures are bypassed. All terminals must be secure, and employees should be prevented from connecting their devices to the company network. In fact, hackers can invade PC-based terminals in the OT environment. Companies should also protect their IT terminals from digital attacks that move horizontally in the OT environment.
