3BHB005171R0101 |  可控硅模块  |  3BHB045647R0001 GVC736CE101  |  3BHB004027R0101

型号：3BHB005171R0101

类别：可控硅模块

成色：全新/非全新

货期：现货

质保：一年

快递：顺丰/德邦

结构：可控硅模块由多个PN结组成，具有一个主极（Anode）、一个辅助极（Cathode）和一个控制极（Gate）。

原理：3BHB005171R0101 当主极和辅助极之间无电压时，可控硅处于关断状态，电流无法通过。当在控制极上施加一个足够的正脉冲电压时，可控硅会被激活并进入导通状态，电流可以通过主极和辅助极之间流动。一旦电流开始流动，控制极上的电压可以降低到一个较低的水平以维持可控硅的导通状态。

3BHB005171R0101 可控硅模块具有以下优点：

体积小、重量轻、结构紧凑。

可靠性高、外接线简单、互换性好。

便于维修和安装，结构重复性好。

装置的机械设计可以简化，价格比分立器件低。

四、应用领域

3BHB005171R0101 可控硅模块的应用领域非常广泛，包括：

电力电子领域：用于交流电源的变换、调节和控制，如电动机的启动、调速和制动，电气加热、电焊、电镀等行业的电源控制，以及交流变压器的控制和调节等。

照明领域：用于LED照明的调节和控制，实现灯光的亮度、颜色温度调节以及闪烁控制和节能控制等。

电磁炉领域：作为电磁炉的核心部件之一，通过控制电流的方向和大小来实现电磁炉的加热和控制。

电动汽车领域：3BHB005171R0101 用于电动汽车的控制系统，实现对电池和电机的控制和调节，如电池的充电和放电控制、电机的调速和制动以及电动汽车的节能控制等。

电力系统领域：用于电力系统的电压和电流控制和调节，实现电力系统的稳定性和可靠性。

3BHB005171R0101 | thyristor module | 3BHB045647R0001 GVC736CE101 | 3BHB004027R0101

Model: 3BHB005171R0101

Category: thyristor module

Finish: New/not new

Delivery time: from stock

Warranty: One year

Express: SF Express/Debon

Structure: The thyristor module is composed of multiple PN junctions, with a main pole (Anode), an auxiliary pole (Cathode) and a control pole (Gate).

Principle: 3BHB005171R0101 When there is no voltage between the main pole and the auxiliary pole, the thyristor is in the off state and the current cannot pass through. When a sufficient positive pulse voltage is applied to the control pole, the thyristor is activated and enters the on-state, and current can flow between the main and auxiliary poles. Once the current begins to flow, the voltage on the control pole can be reduced to a low level to maintain the on-state of the thyristor.

The 3BHB005171R0101 thyristor module has the following advantages:

Small size, light weight, compact structure.

High reliability, simple external wiring, good interchangeability.

Easy maintenance and installation, good repeatability of structure.

The mechanical design of the device can be simplified and the price is lower than that of discrete devices.

4. Application field

3BHB005171R0101 thyristor modules have a wide range of applications, including:

Power electronics: for the conversion, regulation and control of AC power supply, such as motor starting, speed regulation and braking, electrical heating, welding, electroplating and other industries of power control, as well as AC transformer control and regulation.

Lighting field: Used for LED lighting adjustment and control, to achieve the brightness of the light, color temperature adjustment and flicker control and energy saving control.

Induction cooker field: As one of the core components of induction cooker, the induction cooker is heated and controlled by controlling the direction and size of the current.

Electric vehicle field: 3BHB005171R0101 is used in the control system of electric vehicles to realize the control and adjustment of batteries and motors, such as battery charging and discharge control, motor speed regulation and braking, and energy saving control of electric vehicles.

Power system field: Used for voltage and current control and regulation of power system to achieve stability and reliability of power system.
